Дънна платка MSI H110M PC MATE, H110, LGA1151, DDR4, PCI-E(HDMI&DVI&VGA)(CF), 4x SATA 6Gb/s, 2x USB 3.1 Gen1, ATX

MSI H110M PC MATE

CPU

• Supports 6th Gen Intel® Core™ i3/i5/i7 processors, and Intel® Pentium® and Celeron® processors for Socket LGA1151



Chipset

• Intel® H110 Chipset



Main Memory

• 2x DDR4 memory slots, support up to 32GB
- Supports DDR4 2133 MHz
• Dual channel memory architecture
• Supports ECC, un-buffered memory
- ECC UDIMM memory (non-ECC mode)
• Supports Intel® Extreme Memory Profile (XMP)
* Please refer to Compatibility reports for more information of compatible memory.
* DDR4 2133 MHz and higher memory modules will only run at maximum of DDR4 2133 MHz on XMP mode due to Intel® chipset limitation.


Slots

• 1 x PCIe 3.0 x16 slot (supports X16 mode)
• 1 x PCIe 2.0 x16 slot (supports X4 mode)
• 2 x PCIe 2.0 x1 slots
• 3 x PCI slots


Onboard Graphics

• 1 x HDMI™ port, supports a maximum resolution of 4096x2160@24Hz, 2560x1600@60Hz
- Support for HDMI™ 1.4 version.
• 1 x DVI-D port, support a maximum resolution of 1920x1200@60Hz
• 1 x VGA port, supports a maximum resolution of 2048x1536@50Hz, 2048x1280@60Hz, 1920x1200@60Hz


Multi-GPU

• Supports 2-Way AMD® CrossFire™ Technology


On-Board SATA

• Intel® H110 Chipset
• 4 x SATA 6Gb/s ports



USB

• Intel® H110 Chipset
- 4 x USB 3.1 Gen1 (SuperSpeed USB) ports (2 ports on the back panel, 2 ports available through the internal USB connector)
- 6 x USB 2.0 (High-speed USB) ports (4 ports on the back panel, 2 ports available through the internal USB connectors)


Audio

• Realtek® ALC887 Codec
• 7.1-Channel High Definition Audio



LAN

• 1 x Realtek RTL8111H Gigabit LAN controller



Back Panel I/O Ports

- 1 x PS/2 keyboard port
- 1 x PS/2 mouse port
- 1 x HDMI™ port
- 1 x DVI-D port
- 1 x VGA port
- 2 x USB 3.1 Gen1 ports
- 4 x USB 2.0 ports
- 1 x LAN (RJ45) port
- 3 x audio jacks



Internal I/O Connectors

- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 4 x SATA 6Gb/s connectors
- 1 x USB 2.0 connector (supports additional 2 USB 2.0 ports)
- 1 x USB 3.1 Gen1 connector (supports additional 2 USB 3.1 Gen1 ports)
- 2 x 4-pin CPU fan connectors
- 3 x 4-pin system fan connectors
- 1 x Clear CMOS jumper
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 1 x Serial port connector
- 1 x Parallel port connector



Dimension

• 12 in. x 8.7 in. (30.5 cm x 22.0 cm) ATX Form Factor
