Image Sensor OV9712S
Image Resolution 720P (960H Optional)
Effective Pixels 1.0MP, 1280x720
TV System PAL/NTSC
Electronic Shutter 1/25s~1/50,000s , 1/30s~1/60,000s
S/N Ratio ≥50dB
Scanning System Progressive Scan
Lens
Focus Length Board Lens 3.6mm/F2.0
Focus Control Fixed
Lens Type Fixed
Pixels 2M Pixels
Auto Iris Support NO
Night Vision
Infrared LED ￠5 (12µ) x 24PCS （14µ x 18PCS Optional)
Infrared Distance 20M
IR Status Under 10 Lux by CDS
IR Power On CDS Auto Control
Camera Features
Day/Night Auto (ICR) / Color / B&W
OSD Menu Language YES
White Balance Auto/Manual
Gain Control Auto
Noise Reduction 3D NR
Picture Adjustment YES
WDR DWDR
OSD Support Optional
UTC Optional
General
Housing Metal
Bracket YES, Anti-Cut Bracket
Dual Voltage NO
IR Cut Filter YES
Heater NO
Operation Temperature -10℃ ~ +50℃ RH95% Max
Storage Temperature -20℃ ~ +60℃ RH95% Max
Power Source DC12V±10%, 500mA
Dimension ￠94 x 69(H) mm
Weight 400g
Виж още Аналогови и хибридни Longse
Виж всички Аналогови и хибридни в категорията
Image Resolution 720P (960H Optional)
Effective Pixels 1.0MP, 1280x720
TV System PAL/NTSC
Electronic Shutter 1/25s~1/50,000s , 1/30s~1/60,000s
S/N Ratio ≥50dB
Scanning System Progressive Scan
Lens
Focus Length Board Lens 3.6mm/F2.0
Focus Control Fixed
Lens Type Fixed
Pixels 2M Pixels
Auto Iris Support NO
Night Vision
Infrared LED ￠5 (12µ) x 24PCS （14µ x 18PCS Optional)
Infrared Distance 20M
IR Status Under 10 Lux by CDS
IR Power On CDS Auto Control
Camera Features
Day/Night Auto (ICR) / Color / B&W
OSD Menu Language YES
White Balance Auto/Manual
Gain Control Auto
Noise Reduction 3D NR
Picture Adjustment YES
WDR DWDR
OSD Support Optional
UTC Optional
General
Housing Metal
Bracket YES, Anti-Cut Bracket
Dual Voltage NO
IR Cut Filter YES
Heater NO
Operation Temperature -10℃ ~ +50℃ RH95% Max
Storage Temperature -20℃ ~ +60℃ RH95% Max
Power Source DC12V±10%, 500mA
Dimension ￠94 x 69(H) mm
Weight 400g
Виж още Аналогови и хибридни Longse
Виж всички Аналогови и хибридни в категорията
Технически характеристики
| Вид: | Куполни камери |
|---|---|
| Резолюция: | 0.4 - 1.9MP |
| Безжична: | Не |
| Външен монтаж: | Не |
| IR Осветление: | Да |
