HP DesignJet T630 24" / A1 large format plotter printer 2025 edition (5HB09D)

HP DesignJet Printers

The HP DesignJet T600 Series offers high-quality solutions for large-format printing.

Compact size, these printers are made to fit your space.

Responsbibly designed, containing recycled metal.

The world's smallest plotters with high-quality results.

Achieve high-resolution results in a fraction of the space.

Category	Specification
Model	HP DesignJet T630 24-in Printer
Memory	1 GB
What's in the box	Printer, stand, automatic sheet feeder, printhead, introductory ink cartridges, spindle, quick reference guide, setup poster, power cord
Connectivity, Standard	Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, Wi-Fi 802.11a/b/g/n, Wi-Fi Direct
Security Features	HP Wolf Essential Security, Secure boot, Firmware Code Signature Validation, TLS 1.2, 802.1x, and more
Weight	28.9 kg
Package Weight	38 kg
Dimensions (W x D x H)	1013 x 605 x 932 mm
Package Dimensions (W x D x H)	1155 x 575 x 475 mm
Power Input	100-240 V (±10%), 50/60 Hz (±3 Hz), 1200 mA max
Power Consumption	<35 W (printing), <5.6 W (ready), <2.1 W (sleep), <0.2 W (off)
Software Included	HP Click App (Windows/macOS), HP Click Driver (Windows 11), HP app (Windows/macOS/Android/iOS)
Print Cartridges/Bottles	4 (C, M, Y, K) cartridges
Ink Types	Dye-based (C, M, Y), pigment-based (K)
Ink Drop	5.5 pl (C, M, Y), 12 pl (K)
Print Cartridge/Bottle Volume	80 ml (K), 38 ml (K), 29 ml (C, M, Y) per cartridge
Print Head Nozzles	1376
Print Head Count	1 (cyan, magenta, yellow, black)
High Capacity Page Yield (Color)	20 ml of ink yields 101 A1 pages (including maintenance routines)
Functions	Print
Print Quality (Best)	Up to 2400 x 1200 optimized dpi
Internal Storage	None
Print Speed	30 sec/page on A1, 76 A1 prints per hour
Print Technology	HP Thermal Inkjet
Print Languages	HP-GL/2, HP-RTL, CALS G4, JPEG, URF
Printer Drivers Included	Raster driver (macOS/Windows), HP-GL/2 driver (Windows), HP Click Driver (Windows 11)
Model Size	610 mm
Remote Print Enabled	Yes
Non-printable Area (Cut-sheet)	5 x 5 x 5 x 17 mm (manual feed), 5 x 5 x 5 x 5 mm (input tray)
Non-printable Area (Roll Media)	5 x 5 x 5 x 5 mm
Printing Path	HP Click App, HP Click Driver, HP app, Windows/macOS drivers, HP-GL/2 driver, AirPrint, Android Print Service, ChromeOS support, Email printing
Line Accuracy	±0.1%
Theoretical Minimum Line Width	0.02 mm
Multi-size Printing	Yes
Maximum Optical Density (Black)	8 L* min/2.10 D
Media Sizes Supported	A4, A3, A2, A1 (auto sheet feeder, manual feed)
Custom Media Sizes	210 x 279 mm to 610 x 1897 mm (manual feed)
Media Types	Bond, coated, heavyweight coated, plain, blueprint, film, photographic paper, self-adhesive
Recommended Media	HP Universal Bond Paper, HP Coated Paper, HP Heavyweight Coated Paper
Media Weight (Recommended)	60 to 280 g/m² (roll/manual feed), 60 to 220 g/m² (auto sheet feeder)
Maximum Media Width	610 mm
Output Handling	Sheet feed, roll feed, automatic sheet feeder, media bin, automatic horizontal cutter
Roll External Diameter	100 mm
Roll Maximum Input	1
Roll Maximum Weight	4.1 kg
Media Thickness	Up to 11.8 mil
Media Thickness (Metric)	Up to 0.3 mm
Primary Applications	Line drawings, Presentations, Renderings
