Дънна платка Gigabyte B650 Gaming X (rev 1.0), B650, AM5, DDR5, PCI-E 4.0 (HDMI&DP), 3x M.2, 4x SATA 6Gb/s, 1x USB 3.2 Gen 2 Type-C, 2x USB 3.2 Type-A, 2.5GbE, ATX

Gigabyte B650 Gaming X (rev 1.0)

• AMD Socket AM5：Supports AMD Ryzen 7000 Series Processors
• Unparalleled Performance：Direct 8+2+1 Phases Digital VRM Solution
• Dual Channel DDR5：4* SMD DIMMs with AMD EXPO & Intel XMP Memory Module Support
• SuperSpeed Storage：3* PCIe 4.0 x4 M.2 Connectors
• Advanced Thermal Design & M.2 Thermal Guard：To Ensure VRM Power Stability & 25110 M.2 SSD Performance
• EZ-Latch：PCIe x16 Slot with Quick Release Design
• Fast Networks：2.5GbE LAN
• Extended Connectivity：DP, HDMI, Rear USB-C® 10Gb/s, Front USB-C® 20Gb/s
• Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
• Q-Flash Plus：Update BIOS Without Installing the CPU, Memory and Graphics Card

Tech specs:

   CPU
       AMD Socket AM5, support for: AMD Ryzen 7000 Series Processors

   Chipset
       AMD B650

   Memory
       Support for DDR5 8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800 MT/s memory modules
       4 x DDR5 DIMM sockets supporting up to 192 GB (48 GB single DIMM capacity) of system memory
       Dual channel memory architecture
       Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
       Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory modules

   Onboard Graphics
   Integrated Graphics Processor:
       1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz
       * Support for DisplayPort 1.4 version and HDR.
       1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
       * Support for HDMI 2.1 version and HDCP 2.3.
       ** Support native HDMI 2.1 TMDS compatible ports.
   (Graphics specifications may vary depending on CPU support.)

   Audio
       Realtek Audio CODEC
       High Definition Audio
       2/4/5.1/7.1-channel

   LAN
       Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)

   Expansion Slots
   CPU:
       1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16)
       * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
   Chipset:
       2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_1/2)

   Storage Interface
   CPU:
   2 x M.2 connectors (Socket 3, M key, type 25110/2280 support)
       M2A_CPU and M2B_CPU connectors support PCIe 4.0 x4/x2 SSD (PCB rev. 1.0/1.1)
       M2A_CPU connector supports PCIe 5.0* x4/x2 SSD, M2B_CPU connector supports PCIe 4.0 x4/x2 SSD (PCB rev. 1.2)
       * Actual support may vary by CPU.
   Chipset:
       1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD support) (M2C_SB)
       4 x SATA 6Gb/s connectors

   RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
   RAID 0, RAID 1, and RAID 10 support for SATA storage devices

   USB
   CPU:
       1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support
       1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
       1 x USB 3.2 Gen 1 port on the back panel
   CPU + USB 2.0 Hub:
       3 x USB 2.0/1.1 ports on the back panel
   Chipset:
       1 x USB Type-C port with USB 3.2 Gen 2x2 support, available through the internal USB header
       4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
       4 x USB 2.0/1.1 ports available through the internal USB headers

   Internal I/O Connectors
       1 x 24-pin ATX main power connector
       1 x 8-pin ATX 12V power connector
       1 x 4-pin ATX 12V power connector
       1 x CPU fan header
       1 x water cooling CPU fan header
       2 x system fan headers
       1 x system fan/water cooling pump header
       2 x addressable LED strip headers
       2 x RGB LED strip headers
       1 x CPU cooler LED strip/RGB LED strip header
       3 x M.2 Socket 3 connectors
       4 x SATA 6Gb/s connectors
       1 x front panel header
       1 x front panel audio header
       1 x USB Type-C® header, with USB 3.2 Gen 2x2 support
       1 x USB 3.2 Gen 1 header
       2 x USB 2.0/1.1 headers
       1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
       1 x serial port header
       1 x reset button
       1 x reset jumper
       1 x Clear CMOS jumper

   Back Panel Connectors
       1 x Q-Flash Plus button
       1 x DisplayPort
       1 x HDMI port
       1 x USB Type-C® port, with USB 3.2 Gen 2 support
       1 x USB 3.2 Gen 2 Type-A port (red)
       3 x USB 3.2 Gen 1 ports
       3 x USB 2.0/1.1 ports
       1 x RJ-45 port
       3 x audio jacks

   I/O Controller
       iTE I/O Controller Chip

   BIOS
       1 x 256 Mbit flash
       Use of licensed AMI UEFI BIOS
       PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

   Operating System
       Support for Windows 11 64-bit
       Support for Windows 10 64-bit

   Form Factor
       ATX Form Factor; 30.5cm x 24.4cm
