Specifications:

Enclosure Color: Black

Touch Technology & Capacity:

- SAW (IntelliTouch® Surface Acoustic Wave) - Single Touch
- SAW (IntelliTouch® Surface Acoustic Wave) - Dual Touch
- PCAP (TouchPro® Projected Capacitive) - 10 Touch

Touch Interface:

- TouchPro PCAP, IntelliTouch DT - USB 2.0
- IntelliTouch - Dual serial/USB 2.0

Diagonal Size: 27'' diagonal, Active matrix TFT LCD (LED)

On Screen Display:

- Accessible through switches on the unit’s tethered OSD Control box.

- Controls: Menu, Up, Down, Select, Power

- Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Aspect Ratio, Sharpness, Color Temperature, OSD Timeout, OSD Language, OSD H-Position, OSD V-Position, Recall Defaults, Video Priority, Information, Touch On Sleep Mode, Touch Thru (Only available for TouchPro PCAP)

- Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese

- Lockouts: OSD, Power

Aspect Ratio: 16:9

Active Area (mm): 23.53" x 13.23" / 597.6 mm x 336.15 mm

Resolution: 1920 x 1080

Viewing Angle: Horizontal: ±89° or 178° total / Vertical: ±89° or 178° total

Number of Colors: 16.7 million

Brightness (typical): 270 nits

Response Time-total (typical): 12 msec

Contrast Ratio: 3000:1

I/O Ports: Serial port (IntelliTouch only), USB TypeB, RJ45 for OSD remote key, VGA, HDMI, DisplayPort, 12V D/C in

Input Video Format:

- HDMI V1.3 Type A receptacle for HDMI input
- Analog VGA on Female DB-15 connector
- DisplayPort V1.1a - Supports later versions of DisplayPort video input

Input Video Frequency:

- Horizontal: 30 - 82 KHz
- Vertical: 50 - 75 Hz

Video Interface: HDMI, VGA & Display Port

Power Supply: External DC - Optional power brick (sold separately)

Input power connector (Monitor): Coaxial power jack (2.0mm (+0.0 -0.1mm) pin outer diameter, 6.4mm (+/- 0.3mm) barrel inner diameter, 8.8mm (+/- 0.3mm) barrel depth)

Input Voltage: 12VDC +/- 5%

Adapter Output Power Connector: DC barrel plug (2.1mm (+/- 0.1mm) pin inner diameter, 5.5mm (+/- 0.05mm) barrel outer diameter, 9.5mm (+/- 0.3mm) barrel length)

Power Consumption (Typical):

- ON (Default - 75% Brightness): 21 W
- ON (Typical - 100% Brightness): 27 W
- SLEEP FROM PC (monitor + adapter): 1.5 W
- OFF (monitor + adapter): 0.5 W

Dimensions:

- Bezel: 24.93" x 14.74" x 1.65" / 633.2 mm x 374.4 mm x 41.8 mm
- Zero-Bezel: 25.36" x 15.29" x 1.6" / 644.2 mm x 388.4 mm x 40.6 mm

Shipping Box Dimensions: 30.79" x 20.87" x 7.87" / 782 mm x 530 mm x 200 mm

Weight (Unpackaged): 16.09 lbs / 7.3 Kg

Weight (Packaged): 22.49 lbs / 10.2 Kg

Operating Temperature: 0°C to 40°C / 32°F to 104°F

Storage Temperature: -20°C to 60°C / -4°F to 140°F

Humidity:

- Operating: 20% to 80%
- Storage: 10% to 95%

Sealability:

- Touchscreen sealed to bezel
- Touchscreen sealed to LCD

MTBF: 50,000 hours demonstrated
