Name: Етикетен принтер Brother TD-2320DSA300, 300dpi, 64MB Flash памет, ширина на етикета до 63mm, USB, Wi-Fi
Brand: Brother
SKU: PRSPBROTHERTD2320DSA300
Price: 811.42 EUR
Availability: InStock

Описание Характеристики Ревюта / Въпроси Документация

Brother TD-2320DSA300

Key features:

• Compact and mobile design
• Seamless intergration: Enhanced language emulation with support for ZPL2, EPL and DPL command languages
• Two power options: AC adaptor and optional rechargeable battery 3 **
• Customisable with various options (label peeler, cutter, battery)3 **
• Auto media configuration for easy setup
• 300dpi print resolution
• Built-in 3.5" color touchscreen display
• USB connectivity (serial connectivity available as optional accessory with PA-SCA-002)
• Up to 152mm/second print speed
• 256MB RAM, 64MB Flash
• Linerless media support

Bluetooth profile

SPP(Serial Port Profile), OPP, HCRP, GATT
(Low Energy)
iAP supported

WLAN security

Authentic method (encryption scheme)
Infrastructure mode:
• (Personal) WEP, WPA-PSK (TKIP/AES), WPA2-PSK (AES), WPA3-SAE (AES)
• (Enterprise) EAP-FAST, PEAP, EAP-TLS, EAP-TTLS
Wireless direct: WPA2-PSK (AES)

Operating system support

Microsoft Windows 10, Windows 11
Microsoft Windows Server 2016/2019/2022
Linux

SDK support

Windows B-PAC SDK. Android 10 or later, iOS 16 or later

Printer commands

P-touch Template, ESC/P, Raster and ZPL 2, EPL 2, DPL, CPCL emulations

Built in fonts (ESC/P)
Fixed: Letter Gothic Bold, Helsinki, Gothic
Scalable: Letter Gothic Regular, Helsinki, Brussels, Gothic, San Diego, Brougham

Built in fonts (P-Touch template)
Scalable: Letter Gothic Regular, Helsinki, Brussels, Gothic

Built in fonts (ZPL)
Fixed: Letter Gothic Bold, Symbol, OCR-A, OCR-B ; Scalable: Utah Condensed Bold

Specifications

General

Technology	Direct thermal
Maximum media width (mm)	63mm
Buttons	Power , Feed, Print
Display	None
Memory capacity	64MB

Connectivity

Serial	Yes (Requires optional cable)
USB interface	USB 2.0 Full Speed (Type C)

Dimensions and weights

Dimensions

119mm (W) x 224mm (D) x 158mm (H)

Operating systems & software

Supported Operating Systems

Windows (10, 11, Server 2016, Server 2019, Server 2022)

Operating Environment

Operating Humidity	20% - 80 %
Operating Temperature	5°C - 40°C
Storage Humidity	10% - 90%
Storage Temperature	-20°C - 60°C

Printing

One Dimensional Barcode Symbology	CODABAR(NW7), Code128, Code39, EAN13(JAN13), GS1 DataBar (RSS), GS1 Databar(Omnidirectional/Truncated/Stacked/Stacked Omnidirectional/Limited/Expanded/Expanded Stacked), GS1-128(UCC/EAN-128), POSTNET, UPC-A, UPC-E, ITF14, Intelligent Mail Barcode
Two Dimensional Barcode Symbology	QR Code, MaxiCode, PDF417, DataMatrix, Aztec
Maximum Print Length	3000mm
Printing Resident Fonts	Letter Gothic Bold, Gothic, Brussels, Helsinki, Letter Gothic Regular
Resolution (dpi)	300
Printing Maximum Label Width	63mm
Printing Maximum Roll Core Diameter	12,7mm
Supported commands	Raster, P-touch Template, ZPL 2 emulation, CPCL emulation, ESC/P
