APC BX1200MI

Серията APC BackUPS BX е ценово ефективно решение за защита на захранването в дома и домашния офис. Широката гама VA на серията с първокласни функции допълнително дава възможност за използване на единични UPS

Technical Specifications

Physical
Cable length: 1.22 m
Colour: Black
Depth: 39 cm
Height: 19 cm
Net weight: 7.6 kg
Width: 14 cm

Input
network frequency: 50/60 Hz +/- 5 Hz auto-sensing
plug standard: IEC 60320 C14
input voltage limits: 140...300 V
input voltage: 230 V

Output
Rated power in W: 650 W
Maximum configurable power in W: 650 W
Output frequency: 50/60 Hz +/- 1 Hz sync to mains
UPS type: Standby
Wave type: Stepped approximation to a sinewave
Nb of power socket outlets: 6 IEC 60320 C13
Output voltage: 230 V

Conformance
product certifications: CE
standards: EN/IEC 62040-1, EN/IEC 62040-2, CE
equipment protection policy

Environmental
ambient air temperature for operation: 0…40 °C
relative humidity: 0…95 % non-condensing
operating altitude: 0...3000 ft
ambient air temperature for storage: -15…40 °C
storage altitude: 0.00…914.40 m
acoustic level: 40 dBA
IP degree of protection: IP20

Batteries & Runtime
battery type: Lead-acid battery
Battery recharge time: 8 h

Communications & Management
control panel: LED Status display with on line : on battery
alarm: Alarm when on battery : distinctive low battery alarm

Surge Protection and Filtering
Surge energy rate: 273 J
Data line protection: RJ45 10/100/1000 Base-T Ethernet protection

Packing Units
Package 1 Weight: 8.6 kg
Package 1 Height: 29.7 cm
Package 1 width: 23.5 cm
Package 1 Length: 49.5 cm
