Eaton 9E 3000i Rack 9E3000IR
Икона нов продуктИкона изгоден продукт
Eaton 9E 3000i Rack 9E3000IREaton 9E 3000i Rack 9E3000IR
ОписаниеХарактеристикиРевюта / ВъпросиДокументацияВземи на изплащане

The Eaton 9E UPS gives IT managers an easy way to manage the power in their data center, without having to worry about cost, space or downtime. Developed specifically for IT managers, the 9E confronts typical data center problems head on. It addresses ROI, energy costs, remote management, and efficiency... giving you more time to focus on other important data center issues.

Efficient power managementWith an efficiency of up to 91% and an Eco mode that boosts efficiency to 97%, the Eaton 9E UPS ensures optimal power usage and reduced energy costs. Its power factor of 0.99 further maximizes the utility of electrical power, making it an ideal solution for energy-conscious businesses.Reliable battery technologyFeaturing a 9 Ah lead-acid battery with hot-swappable and sealed capabilities, this UPS provides dependable power backup. The technology allows for safe and easy maintenance, ensuring your operations are protected against power interruptions.Comprehensive connectivityEquipped with RS-232 and USB management interfaces, along with a communication slot for expansion, the Eaton 9E offers versatile connectivity options. This ensures seamless integration and management of the UPS within various IT environments.Advanced protection featuresThe Eaton 9E comes with an array of protection features including an auto shutdown circuit, deep discharge protection, and temperature-compensated battery charging. These features safeguard your equipment from power anomalies and extend the life of the UPS.Flexible installation optionsDesigned for both rack-mountable and freestanding setups, and including a rack mounting kit, this UPS offers flexibility in deployment. Its 2U height and compatibility with 19" racks make it an easy fit in any server room or data center.

Specifications:

Product Length/Depth608 mm
Product Height86.5 mm
Product Width438 mm
Product Weight31.3 kg
CompliancesCE Marked
TUV
CertificationsIEC/EN 62040-1
IEC/EN 62040-2
CE
Battery typeSealed, lead-acid
Battery replacementReplacable batteries
Battery quantity6
Battery management
  • Temperature compensated charging method
  • Automatic battery test
  • Deep discharge protection
Battery rating12 V / 9 Ah
Extended battery capabilityYes
Receptacle(6) C13 + (1) C19
Voltage230V
Wattage2700 W
Output power factor0.9
Output voltage range220/230/240 V +/- 2%
Output waveformSine wave
Output nominal voltage230V default (220/230/240V)
Voltage distortion output (linear load) - max3
Feed type1
TopologyOnline/Double-conversion
VA rating3000 VA
Input connectionC14
Input nominal voltage230V default (220/230/240V)
Nominal frequency50/60 Hz
Input power factor>.99
Input cord length1.8m
Input frequency range40-70 Hz
Includes network cardNo
Communication
  • USB port (HID compliant)
  • Serial port (RS232)
  • Mini-terminal block for remote power off
Ethernet interfaceNo
User interfaceMultilingual LCD display
Potential free switch contactYes
Expansion slotsOne slot for optional communication card
Software compatibilityEaton Intelligent Power Manager, Eaton Intelligent Power Protector
Type of interfaceOther
Altitude3000 m
Noise level<45 dB at 1 meter
Temperature range0° to 40°C (32° to 104°F)
Relative humidity0-96% non-condensing
Construction type482.6 mm (19 inch) device
Package contents
  • UPS
  • (2) IEC-IEC output cables
  • USB cable
  • Rack-mounting kit (rails and brackets)
  • Safety instructions
  • Quickstart guide
Phase (output)1
Internal bypassYes
Auto shutdown functionYes
ColorBlack
Efficiency91
Rack mounting kitYes
Phase (input)1
Hot swap powerNo
