System Information
| CPU |
- Multimedia SoC (System-on-Chip)
|
| Flash |
|
| RAM |
|
|
Camera Features
| Image sensor |
|
| Maximum Resolution |
|
| Lens Type |
|
| Focal Length |
- f = 2.8 mm
- f = 3.6mm (FD8169-F3)
|
| Aperture |
|
| Field of View |
- FD8169
- 105° (Horizontal)
- 87° (Vertical)
- 135° (Diagonal)
- FD8169-F3
- 93° (Horizontal)
- 50° (Vertical)
- 116° (Diagonal)
|
| Shutter Time |
- 1/5 sec. to 1/32,000 sec.
|
| WDR Technology |
|
| Day & Night |
- Removable IR-cut filter for day & night function
|
| Minimum Illumination |
- 1.22 Lux @ F2.0 (Color)
- 0.008 Lux @ F2.0 (B/W)
- 0 Lux @ IR LED ON
|
| Pan range |
|
| Tilt range |
|
| Rotation Range |
|
| Pan / Tilt / Zoom |
- ePTZ
- 48x digital zoom (4x on IE plug-in, 12x built-in)
|
| IR Illuminators |
- Built-in IR illuminators, effective up to 15 meters with Smart IR
- IR LED*6
|
| On-board Storage |
- MicroSD/SDHC/SDXC card slot
|
|
Video
| Compression |
|
| Maximum Frame Rate |
- 30 fps @ 1920x1080 in both compression
|
| Maximum Streams |
|
| S/N Ratio |
|
| Dynamic Range |
|
| Video Streaming |
- Adjustable resolution, quality and bit rate
- Configurable video cropping for bandwidth saving
|
| Image Settings |
- Adjustable image size, quality and bit rate
- Time stamp, text overlay, flip & mirror
- Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks
- Scheduled profile settings, 3D Noise Reduction
|
|
Network
| Users |
- Live viewing for up to 10 clients
|
| Protocols |
- IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP
|
| Interface |
- 10Base-T / 100BaseTX Ethernet (RJ-45)
- * It is highly recommended to use standard Cat. 5e & Cat. 6 cables which are compliant with the 3P/ETL standard.
|
| ONVIF |
- Supported, specification available at www.onvif.org
|
|
Intelligent Video
| Video Motion Detection |
- Triple-window video motion detection
|
|
Alarm and Event
| Alarm Triggers |
- Video motion detection, manual trigger, periodical trigger, system boot, recording notification, camera tampering detection
|
| Alarm Events |
- Event notification using digital output, HTTP, SMTP, FTP and NAS server
- File upload via HTTP, SMTP, FTP and NAS server
|
|
General
| Connectors |
- RJ-45 for Network/PoE connection
|
| LED Indicator |
- System power and status indicator
|
| Power input |
- DC12V
- IEEE 802.3af PoE Class 3
|
| Power consumption |
- Max: 6.5 W (DC12V)
- Max: 7.5 W (PoE)
|
| Dimensions |
|
| Weight |
|
| Safety Certifications |
- CE C-Tick FCC ( Class B ) LVD VCCI
|
| Operating Temperature |
- Starting Temperature: 0°C ~ 50°C (32°F~122°F)
- Working Temperature: -10°C ~ 50°C (14°F ~ 122°F)
|
|
System Requirements
| Operating System |
- Microsoft Windows 7 / Vista / XP / 2000
|
| Browser |
- Mozilla Firefox 7~10 ( Streaming only )
- Internet Explorer 7/8/9
|
| Other Players |
- VLC: 1.1.11 or above
- QuickTime: 7 or above
|
|
