InSight S425
VIGI 2MP Full-Color Turret Network Camera
- 2MP High Definition and 24h Full-Color
- Human & Vehicle Classification
- Smart Detection
- LightPro Night Vision
- Built-In Microphone
- Smart Video Enhancement Technology
- IP67 Waterproof and IK08 Vandal-Proof
- H.265+ Compression Technology
Human & Vehicle Classification
Distinguish humans and vehicles from other objects and receive more accurate event notifications.
| Specification | Details |
|---|---|
| Image Sensor | 1/3” Progressive Scan CMOS |
| Shutter Speed | 1/3 to 1/10000 s |
| Slow Shutter | Yes |
| Minimum Illumination | 0.01 Lux; 0 Lux with IR/White light |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Unified / Scheduled / Auto |
| Lens Type | Fixed Focal Lens |
| Focal Length | 2.8 |
| Aperture | F2.0 |
| FOV (2.8 mm) | Horizontal FOV: 98.8°, Vertical FOV: 53.5°, Diagonal FOV: 117° |
| Lens Mount | M12 |
| DORI Distance (2.8 mm) | Detect: 154.2 ft (47 m), Observe: 62.3 ft (19 m), Recognize: 29.5 ft (9 m), Identify: 16.4 ft (5 m) |
| Angle Adjustment Range | Pan: 0° to 360°, Tilt: 0° to 85°, Rotation: 0° to 360° |
| Illuminator On/Off Control | Auto / Scheduled / Always on / Always off |
| Integrated Infrared-White LED | Quantity: 2; IR Range: 98 ft (30 m); White LED Range: 98 ft (30 m); IR Wavelength: 850 nm |
| Max. Resolution | 1920 × 1080 |
| Main Stream Frame Rate | 50Hz: 1/5/10/15/20/25 fps; 60Hz: 1/5/10/15/20/25/30 fps |
| Main Stream Resolution | 1920×1080, 1280×960, 1280×720 |
| Main Stream Rotation Note | If image rotation is set to 90°, frame rate supports up to 20 fps |
| Sub-Stream Frame Rate | 50Hz: 1/5/10/15/20/25 fps; 60Hz: 1/5/10/15/20/25/30 fps |
| Sub-Stream Resolution | 848×480, 704×576, 640×480, 640×360, 352×288, 320×240 |
| Sub-Stream Rotation Note | If image rotation is set to 90°, frame rate supports up to 20 fps |
| Bit Rate Control | CBR, VBR |
| Video Compression | Main Stream: H.265+/H.265/H.264+/H.264; Sub-Stream: H.265/H.264 |
| H.264 Type | High Profile |
| H.264+ | Main Stream Supported |
| H.265 Type | Main Profile |
| H.265+ | Main Stream Supported |
| Video Bit Rate | Main Stream: 256 Kbps to 4 Mbps; Sub-Stream: 64 Kbps to 512 Kbps |
| Image Settings | Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software |
| Image Enhancement | BLC / 3D DNR / HLC / SmartIR |
| Wide Dynamic Range | DWDR |
| SNR | ≥ 52 dB |
| Image Parameters Switch | Yes |
| Privacy Mask | Up to 4 Masks |
| ROI | 1 Region |
| OSD Setting | Yes |
| Audio Communication | N/A |
| Audio Input | Yes (Built-in Microphone) |
| Audio Output | N/A |
| Audio Compression | Yes |
| Audio Sampling Rate | 8 KHz |
| Environment Noise Filtering | Yes |
| Audio Bit Rate | 64 Kbps (G.711 alaw) |
| Protocol | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP |
| ONVIF | Yes |
| API | Open Network Video Interface (Profile S/T) |
| Simultaneous Live View | 3 Main Streams & 3 Sub-Streams |
| Client | VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool, VIGI PC Client |
| Web Browser | Google Chrome® 57+, Firefox® 52+, Safari® 11+, Microsoft® Edge 91+ |
| Cloud | Yes |
| Security | Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
| Smart Event | Intrusion Detection, Line-Crossing Detection, Region Entering Detection, Region Exiting Detection, People Detection, Vehicle Detection |
| Basic Event | Motion Detection (Enhanced with Human & Vehicle Classification), Video Tampering Detection, Exception (Illegal Login) |
| Alarm Linkage | Upload to FTP Server, Push Notifications, Send to Alarm Server, Email Alarm |
| Network Interface | 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
| Alarm | N/A |
| Reset Button | N/A |
| Power Interface | DC Power Port |
| On-board Storage | N/A |
| Built-in Microphone | Yes; Records Anything Going on within a 16.4 ft (5 m) Radius of the Camera |
| Built-in Speaker | N/A |
| Audio Interface | N/A |
| Operating Temperature | -30 °C to 60 °C (-22 °F to 140 °F) |
| Storage Temperature | -40 °C to 60 °C (-40 °F to 140 °F) |
| Operating Humidity | 95% or Less (Non-Condensing) |
| Storage Humidity | 95% or Less (Non-Condensing) |
| Package Content | VIGI Network Camera, Quick Start Guide, Waterproof Cable Attachments, Mounting Accessories |
| Material | Metal |
| Net Weight | 0.43 Kg |
| Power Supply | 12V DC ± 5%, Max. 7.4 W, 5.5 mm Coaxial Power Plug; PoE: 802.3af/at, Class 0, Max. 8 W |
| Protection | IP67 Waterproof, IK08 Vandal Proof |
| Product Dimensions (L × W × H) | Ø4.4 × 3.4 in (Ø112.2 × 87.2 mm) |
Виж още Цифрови IP камери TP-Link
Виж всички Цифрови IP камери в категорията
Технически характеристики
| Вид: | Куполни камери |
|---|---|
| Резолюция: | FullHD |
| Управляема: | Неуправляема |
| Аудио: | Микрофон |
| Безжична: | Не |
| Външен монтаж: | Да |
| IR Осветление: | Да |
| Термокамера: | Не |
