Name: WiFi реле Shelly EM Gen3, за MCB автоматични предпазители, до 30m обхват, Bluetooth, бяло
Brand: Shelly
SKU: HOAUSHELLYS3EM002CXCEU
Price: 135.37 BGN
Availability: InStock

Описание Характеристики Ревюта / Въпроси Вземи на изплащане

Shelly EM Gen3

Monitor and save energy from anywhere

Unlock the power of smart energy use with detailed insights into your appliances' power consumption patterns. Integrate Shelly EM Gen3 into standard electrical wall boxes, behind power sockets, light switches, or other places with limited space. By identifying how and when your connected appliances use energy, you can optimize usage for maximum efficiency and lower your electricity bills.

Wi-Fi and Bluetooth connectivity

Connect Shelly ЕМ Gen3 to your Wi-Fi network. No HUB required! Quick inclusion via Bluetooth or use it as a Bluetooth gateway.

Current transformers connection

Connect up to 2 current transformers. No need for extra wiring!

Dry contact switch

For contactor control of heavier loads

Local data storage

Data logs stored on device for up to 10 days in 1-minute intervals. When connected to the cloud, data logs go back to 365 days.

Smart Scenes

Set custom scenes by combining Shelly EM Gen3 with your other Shelly devices to control energy use.

Scripting

Fully supports scripting, allowing you local control and custom functionalities.

Specifications

Environmental

Ambient working temperature:	-20 °C to 40 °C / -5 °F to 105 °F
Humidity:	30 % to 70 % RH
Max. altitude:	2000 m / 6562 ft

Screw terminals max torque:	0.4 Nm / 3.5 lbin
Conductor cross section:	0.5 to 4 mm² / 20 to 11 AWG (solid, stranded, and bootlace ferrules)
Conductor stripped length:	6 to 7 mm / 0.24 to 0.28 in
Mounting:	Wall console, Electrical cabinet
Shell material:	Plastic

Electrical

Power supply:	110 - 240 V~ 50/60 Hz
Power consumption:	< 1.2 W
External protection:	2 A, tripping characteristic B or C, 6 kA interrupting rating, Energy limiting class 3

Output circuits ratings

Max. switching voltage:	240 V~
Max. switching current:	2 A/240 V~

Sensors, meters

Voltmeter (AC):	110-240 V~ 50/60 Hz
Voltmeter accuracy:	±2%
Ammeter (AC):	0 - 80A
Ammeter accuracy:	±2 % (2 - 50 A), ±2 % (1 - 2 A), ±5 % (0 - 1 A)
Compatible current transformers:	CT 50A CT 80A
Power and energy meters:	Active and apparent power Active and apparent energy Power factor Fundamental active and fundamental reactive energy
Channel-to-channel calibration minimum load:	500 W
No load threshold:	30 VA per channel
Measurement data storage:	At least 10 days of 1 min data resolution
Data export:	CSV for PQ recorded values JSON format export through RPC
Internal-temperature sensor:	Yes

Radio

Wi-Fi

Protocol:	802.11 b/g/n
RF band:	2412 - 2472 МHz
Max. RF power:	< 20 dBm
Range:	Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions)

Bluetooth

Protocol:	4.2
RF band:	2402 - 2480 MHz
Max. RF power:	< 4 dBm
Range:	Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions)

Microcontroller unit

CPU:	ESP-Shelly-C38F
Flash:	8 MB

Firmware capabilities

Schedules:	Yes
Webhooks (URL actions):	20 with 5 URLs per hook
Scripting:	Yes
MQTT:	Yes
Encryption:	Yes (Transport level)
Authentication:	Yes (Application and transport level)
