TS-632X
Cost-effective 6-bay 10GbE NAS, designed to accelerate your workloads
Unlock the potential of 6-bay storage capacity and harness the speed of 10GbE with the TS-632X! This versatile storage solution offers secure backup, rapid transmission, support for container applications, and much more. Cost-effective yet powerful, the TS-632X streamlines workflow efficiency without exceeding your budget.
Quad-core for multitasking
Quad-core 2.0GHz processor and 4 GB non-ECC RAM (expandable to 16 GB, supports ECC RAM)
Dual-port 10GbE SFP+
High-speed 10GbE connectivity enhances transfer speed for intensive data transmission and shortens backup time.
2.5GbE is a must!
Leverage SMB Multichannel or Port Trunking with built-in dual 2.5GbE ports to increase bandwidth and access speed.
PCIe Gen 3 expandability
Install a PCIe expansion card to add 2.5/5/10GbE connectivity or M.2 SSD slots to the NAS for more I/O potential.
Faster USB transfer and backup
Two USB 3.2 Gen 1 (5Gbps) ports with One Touch Copy support allow faster backup to/from USB devices.
Centralized backup and snapshot protection
Easily back up different types of data and endpoints and create snapshots regularly to prevent ransomware threats.
| Category | Specification |
|---|---|
| CPU | AnnapurnaLabs (Amazon) Alpine AL524, 4-core, 2.0 GHz |
| CPU Architecture | 64-bit ARM |
| Floating Point Unit | — |
| Encryption Engine | — |
| System Memory | 4 GB DDR4 SODIMM |
| Maximum Memory | 16 GB (1 × 16 GB) |
| Memory Slot | 1 × DDR4 SODIMM, ECC supported |
| Flash Memory | 512 MB (Dual boot OS protection) |
| Drive Bays | 6 × 3.5-inch SATA (6 Gb/s, 3 Gb/s) |
| Drive Compatibility | 3.5″ SATA HDDs; 2.5″ SATA HDDs; 2.5″ SATA SSDs |
| Hot-swappable Drives | — |
| SSD Cache Acceleration Support | — |
| 2.5 Gigabit Ethernet Ports | 2 × 2.5G/1G/100M |
| 10 Gigabit Ethernet Ports | 2 × 10GbE SFP+ |
| Wake on LAN (WOL) | — |
| Jumbo Frame | — |
| PCIe Slot | 1 × PCIe Gen 3 x4 (Card size: 190 × 68.9 × 18.76 mm / 7.48 × 2.71 × 0.74 in) |
| USB Ports | 2 × USB 3.2 Gen 1 |
| Form Factor | Tower |
| LED Indicators | Power, Status, LAN, USB, HDD1–6 |
| Buttons | Power, Reset, USB Auto Copy |
| Dimensions (H × W × D) | 226.5 × 235 × 165 mm |
| Weight (Net) | 2.5 kg |
| Weight (Gross) | 4.96 kg |
| Operating Temperature | 0–40 °C (32–104 °F) |
| Storage Temperature | −20–70 °C (−4–158 °F) |
| Relative Humidity | 5–95% RH (non-condensing), wet bulb: 27 °C (80.6 °F) |
| Power Supply Unit | 120 W adapter (12 VDC), 100–240 VAC |
| Fan | 2 × 90 mm, 12 VDC |
| System Warning | Buzzer |
