Fits In. Watches Out.
Inconspicuous surveillance with state-of-the-art technology. The D22 FixDome from MOBOTIX adapts perfectly to any task. Exchangeable lenses, various mounting and configuration options including vandalism set support unlimited application possibilities.
MOBOTIX HiRes video replaces up to 6 cameras …
* Attractively designed FixDome camera featuring exchangeable lenses from tele to wide-angle
* Numerous installation options both indoor and outdoor
* On-wall set with space for extension modules (battery, UMTS, WLAN, etc.)
* Integrated DVR with HiRes video recording
* Robust, low-maintenance and weatherproof from -30° to +60°C (-22° to +140°F), (IP65)
* Digital continuous zoom, pan and tilt
* Can be upgraded to an intercom system with the MOBOTIX ExtIO module
Technical Specifications D22 MonoDome
Models - Basic, IT, IT-Night, Sec, Sec-Night
Lenses - 22 to 135 mm format, horizontal angle 90° to 15°
Sensitivity:
Color: 1 lux (t=1/60 s), 0,05 lux (t=1/1 s)
B/W: 0,1 Lux (t=1/60 s), 0,005 Lux (t=1/1 s)
Sensor - 1/2“ CMOS, progressive scan
Max. image resolution - Color: 2048 x 1536 (3Mega), Black/White: 1280 x 960 (Mega)
Image format:
2048 x 1536, 1280 x 960, 1024 x 768, 800 x 600,
768 x 576 (D1), 704 x 576 (TV-PAL), 640 x 480,
384 x 288, 352 x 288, 320 x 240, 160 x 120;
free image format selection (e.g. 1000 x 200 for skyline)
Max. frame rate (M-JPEG) (Live/Recording):
VGA: 16 fps, TV-PAL: 12 fps, Mega: 6 fps, 3Mega: 4 fps
Max. Video stream (MxPEG) (Live/Recording/Audio):
VGA: 30 fps, TV-PAL: 24 fps, Mega: 14 fps, 3Mega: 10 fps
Image compression - MxPEG, M-JPEG, JPG, H.263 (Video-VoIP-Telephony)
Internal DVR - Slot for SD card (up to 16 GB)
External storage - Directly on NAS and PC/Server without additional recording software
Software (inclusive) - Video-Management-Software MxEasy, Control room software MxControlCenter
Image processing:
Backlight compensation, automatic white balance, image
distortion correction, video sensor (motion detection)
Virtual PTZ - Digital Pan/Tilt/Zoom, continuous 8x zoom
Alarm/Events:
Triggering of events by integrated multiple-window motion detection, external signal, temperature sensor, notification over email, FTP, IP-Telephony (VoIP, SIP), visual/acoustic alarm Pre- and post-alarm images
Audio - Optional via ExtIO, video VoIP supported
Interfaces - Ethernet 10/100, USB, Audio (microphone/speaker)
Audio/Telephony:
VoIP, SIP, two-way speaker, remote controlling of the camera in- and outputs, event notification
Security:
User-/Group management, HTTPS/SSL, IP address filter, IEEE 802.1x, Intrusion Detection
Certificates:
BGV C9 (“UVV”), EMV (living environments, industry), EN 50155 (shock, vibration, temperature), CE, FCC
Power supply - Year-round power over Ethernet (IEE 802.3af; Class 0), Netpower-Adapter, typ. 2,5 W
Operating conditions - IP65 (DIN EN 60529), -30° bis +60 °C (-22°F to +140°F)
Dimensions - ? x H: 16 x 8,6 cm,
Weight: ca. 350 g
Standard delivery:
Housing (high-resistance composites - PBT-PC), white, shockproof polycarbonate dome transparent, free choice of lenses, mounting parts, allen wrench, patch cable, manual, software
http://www.mobotix.com/other/products/monodome_d22m
Виж още Цифрови IP камери Mobotix
Виж всички Цифрови IP камери в категорията
Inconspicuous surveillance with state-of-the-art technology. The D22 FixDome from MOBOTIX adapts perfectly to any task. Exchangeable lenses, various mounting and configuration options including vandalism set support unlimited application possibilities.
MOBOTIX HiRes video replaces up to 6 cameras …
* Attractively designed FixDome camera featuring exchangeable lenses from tele to wide-angle
* Numerous installation options both indoor and outdoor
* On-wall set with space for extension modules (battery, UMTS, WLAN, etc.)
* Integrated DVR with HiRes video recording
* Robust, low-maintenance and weatherproof from -30° to +60°C (-22° to +140°F), (IP65)
* Digital continuous zoom, pan and tilt
* Can be upgraded to an intercom system with the MOBOTIX ExtIO module
Technical Specifications D22 MonoDome
Models - Basic, IT, IT-Night, Sec, Sec-Night
Lenses - 22 to 135 mm format, horizontal angle 90° to 15°
Sensitivity:
Color: 1 lux (t=1/60 s), 0,05 lux (t=1/1 s)
B/W: 0,1 Lux (t=1/60 s), 0,005 Lux (t=1/1 s)
Sensor - 1/2“ CMOS, progressive scan
Max. image resolution - Color: 2048 x 1536 (3Mega), Black/White: 1280 x 960 (Mega)
Image format:
2048 x 1536, 1280 x 960, 1024 x 768, 800 x 600,
768 x 576 (D1), 704 x 576 (TV-PAL), 640 x 480,
384 x 288, 352 x 288, 320 x 240, 160 x 120;
free image format selection (e.g. 1000 x 200 for skyline)
Max. frame rate (M-JPEG) (Live/Recording):
VGA: 16 fps, TV-PAL: 12 fps, Mega: 6 fps, 3Mega: 4 fps
Max. Video stream (MxPEG) (Live/Recording/Audio):
VGA: 30 fps, TV-PAL: 24 fps, Mega: 14 fps, 3Mega: 10 fps
Image compression - MxPEG, M-JPEG, JPG, H.263 (Video-VoIP-Telephony)
Internal DVR - Slot for SD card (up to 16 GB)
External storage - Directly on NAS and PC/Server without additional recording software
Software (inclusive) - Video-Management-Software MxEasy, Control room software MxControlCenter
Image processing:
Backlight compensation, automatic white balance, image
distortion correction, video sensor (motion detection)
Virtual PTZ - Digital Pan/Tilt/Zoom, continuous 8x zoom
Alarm/Events:
Triggering of events by integrated multiple-window motion detection, external signal, temperature sensor, notification over email, FTP, IP-Telephony (VoIP, SIP), visual/acoustic alarm Pre- and post-alarm images
Audio - Optional via ExtIO, video VoIP supported
Interfaces - Ethernet 10/100, USB, Audio (microphone/speaker)
Audio/Telephony:
VoIP, SIP, two-way speaker, remote controlling of the camera in- and outputs, event notification
Security:
User-/Group management, HTTPS/SSL, IP address filter, IEEE 802.1x, Intrusion Detection
Certificates:
BGV C9 (“UVV”), EMV (living environments, industry), EN 50155 (shock, vibration, temperature), CE, FCC
Power supply - Year-round power over Ethernet (IEE 802.3af; Class 0), Netpower-Adapter, typ. 2,5 W
Operating conditions - IP65 (DIN EN 60529), -30° bis +60 °C (-22°F to +140°F)
Dimensions - ? x H: 16 x 8,6 cm,
Weight: ca. 350 g
Standard delivery:
Housing (high-resistance composites - PBT-PC), white, shockproof polycarbonate dome transparent, free choice of lenses, mounting parts, allen wrench, patch cable, manual, software
http://www.mobotix.com/other/products/monodome_d22m
Виж още Цифрови IP камери Mobotix
Виж всички Цифрови IP камери в категорията
Технически характеристики
| Вид: | Управляеми камери (PTZ - Pan/Tilt/Zoom) |
|---|---|
| Външен монтаж: | Да |
| Безжична: | Не |
| IR Осветление: | Не |
| Мрежова: | Не |
| Разделителна способност, max: | 3MP |
