Name: Монитор Vestel XN86 86IN
Availability: OutOfStock

Audio
Number of built-in speakers	2

RMS rated power	12 W

Built-in speaker(s)	Y
Certificates
Certification	CE, EMC
Design
Product colour	Black

Placement supported	Indoor

Panel mounting interface	600 x 400 mm

Product design	Digital signage flat panel

Bezel width (side)	1.2 cm

Bezel width (top)	1.2 cm

Bezel width (bottom)	1.2 cm

VESA mounting	Y

Orientation	Horizontal/Vertical
Display
Contrast ratio (typical)	1200:1

Viewing angle, horizontal	178°

Viewing angle, vertical	178°

Display diagonal	2.18 m (86)

Display brightness	500 cd/m²

Response time	8 ms

Display resolution	3840 x 2160 pixels

Contrast ratio (dynamic)	50000:1

LED backlighting type	Edge-LED

Display technology	IPS

Native aspect ratio	16:9

HD type	4K Ultra HD

Panel life	50000 h

Active display area (W x H)	1895 x 1066 mm

Surface hardness	3H

Haze rate	3%

Native refresh rate	120 Hz
General Information
Marketing Information	External Device Connections You may want to connect your teleconference system, screen sharing system, set-top box or external PCs via HDMI port. For this purposes, our monitors help you to maximize user experience with HDMI CEC (Consumer Electronics Control) and HDMI Hotplug capabilities. Usb Security This series lets your USB and your content to be secured within the back cover of the display. The cover is protected with a screw not allowing any outside intervention. Usb Auto-Play You will be able to show photo and video content automatically with USB Auto-play feature. SoC software gives you a choice to turn on USB auto-play function making it easy for end-users to show any media on the screen and not worry about anything else. OPS Support All our products in this series have compliance with OPS (Open Pluggable Standard). OPS will empower your screens with enhanced processing power and ability to choose Windows or Android as your operating system to fit your specific application. Subtle Design This series’ displays exhibit ultra narrow bezel design eliminating the visual superfluities, directing audience focus on your advertised content. This series is found to be desirable for digital signage specific design: internal usb cover, OPS-slot, detachable power plug, carrying handles and IR extender. SoC Content Management With quad core SoC (System on Chip), this Series displays are the digital signage monitors for both offline designed content and cloud-based managed content. This helps your digital content to be displayed in the displays by content management systems. Display Control Digital Signage Display SoC enables the users to control our displays using RS232 commands in a Local Area Network. Together with the full RS232 command list you can change/set volume, turn on/off the monitor, set a schedule for content display, set a webpage link to be displayed and give a wide range of commands in real-time. Open Platform Support Our SoC supports API (Application Programming Interface) for solution providers/integrators to develop and integrate any HTML5-based to be installed and used on our displays. Daisy Chain The display can mirror the content (to another display) into its display port out coming from its display port in. This set up creates a daisy chain like structure allowing for monitors to be set up as Video Wall mode. Pixel Shifting The Pixel Shifting feature can be activated in order to reduce the potential risk of image sticking when static content is displayed over long periods of time. The feature periodically shifts the image on the display, without causing any interference of the visual experience. Scheduler The built in scheduler is one of the many important included features. The scheduler allows you to plan daily routines of when the display is powered on or off, along with selection of different sources or USB playlists. Signal Failover Our displays have a protection for “No Signal”. If the source is disconnected, the display will either show your customized banner or search for any other signal from video sources. Since blank screen is the worst case scenario for advertisement, failover is one of the critical feature in our signage displays. Crestron Connected Crestron Connected certification complements VESTELs presence with inside the corporate, retail, government, better training and hospitality markets, all of which use expert AV controls. As those sectors hold to evolve with growing necessities for simple-to-use merchandise, seamless integration, dependable answers and community connectivity.
Operational conditions
Operating relative humidity (H-H)	10 - 90%

Operating temperature (T-T)	0 - 40 °C
Packaging content
Remote control included	Y

Cables included	AC, IR

Batteries included	Y

Mounting kit	Y
Packaging data
Package weight	83.5 kg

Package depth	380 mm

Package height	1405 mm

Package width	2163 mm
Performance
Purpose	Universal

Operating hours (hours/days)	24/7
Ports & interfaces
Ethernet LAN	Y

Ethernet LAN (RJ-45) ports	1

DVI port	N

Audio (L/R) in	1

HDMI ports quantity	5

RS-232 interface	Y

HDMI version	2.0

DisplayPorts quantity	2

USB version	2.0

VGA (D-Sub) input ports	1

DisplayPorts out	1

USB ports quantity	4

USB port	Y

HDMI input ports quantity	4

HDMI output ports quantity	1
Power
Power consumption (typical)	280 W

Power consumption (standby)	0.5 W

AC input frequency	50 - 60 Hz

AC input voltage	110 - 240 V
Weight & dimensions
Weight	62.2 kg

Height	1099 mm

Width	1928 mm

Depth	80 mm
