Lenovo ThinkSystem SR530
General
Type: Server
Product Form Factor: Rack-mountable - 1U
Embedded Security: Trusted Platform Module (TPM 1.2 and TPM 2.0)
Server Scalability: 2-way
Localisation: Region: EMEA
Processor / Chipset
CPU: Intel Xeon Silver 4208
Clock Speed: 2.1 GHz
Max Turbo Speed: 3.2 GHz
Number of Cores: 8-core
CPU Qty: 1
Max CPU Qty: 2
Chipset Type: Intel C622
Cache Memory
Installed Size: 11 MB
Cache Per Processor: 11 MB
RAM
Installed Size 32 GB
Technology: DDR4 SDRAM - ECC
Effective Memory Speed 2400 MHz
Rated Memory Speed: 2933 MHz
Form Factor: DIMM 288-pin
Slots: 12 (Total) / 11 (empty)
Features: Registered, Memory Mirroring, Memory Sparing, mixing of different types of memory modules is not supported, Patrol Scrubbing, Demand Scrubbing, Single Device Data Correction (SDDC)
Configuration Features 1 x 32 GB
RAM Supported 384 GB registered - ECC
768 GB Load-Reduced - ECC
Hard Drive
Type: No HDD
Graphics Controller
Graphics Processor: Matrox G200
Video Memory: 16 MB
Video Interfaces: VGA
Networking
Ethernet Ports 2 x Gigabit Ethernet
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller: XClarity Controller (XCC) Enterprise
Expansion / Connectivity
Slots
1 (total) / 1 (free) x LAN-on-Motherboard (LOM)
1 (total) / 1 (free) x PCIe 3.0 x16 - low-profile
1 (total) / 1 (free) x PCIe 3.0 x8 - low-profile
Interfaces
3 x USB 3.0 (1 front, 2 rear)
1 x USB 2.0 (1 in front)
1 x VGA
1 x management - RJ-45
2 x LAN (Gigabit Ethernet) - RJ-45
Miscellaneous
Included Accessories
Tool-less rail kit, C13-C14 rack power cable (2.8 m)
Compliant Standards: TUV GS, BSMI, CISPR 22 Class A, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, CCC, RoHS, UL 60950-1, IEC 60950-1, FCC Part 15 A, GB 17625.1, GB 9254 Class A, VCCI Class A, KN24, EAC, KN22 Class A, NMB-3 Class A, GB 4943.1, BIS, EK1-ITB2000, EN 55022 Class A, CNS 13438 Class A, CNS 14336-1, IEC/EN 60950-1, TR CU 020/2011, TR CU 004/2011, CAN/CSA-C22.2 No. 60950-1
Power
Device Type: Power supply - hot-plug
Power Redundancy: Optional
Power Redundancy Scheme: 1+1 (with optional power supply)
Installed Qty: 1
Max Supported Qty: 2
Voltage Required: AC 100-240 V (50/60 Hz)
Power Provided 750 Watt
80 PLUS Certification 80 PLUS Platinum
Dimensions & Weight
Width: 43.5 cm
Depth: 75 cm
Height: 4.3 cm
Weight: 10.2 kg
