Name: Кутия за компютър Sharkoon M25-V PC
Availability: OutOfStock

Cooling
Front fans installed	1x 120 mm

Number of front fans supported (max)	2

Front fans diameters supported	120 mm

Rear fans diameters supported	120 mm

Top fans diameters supported	120,140 mm

Number of rear fans supported (max)	1

Number of top fans supported (max)	3

Rear fans installed	1x 120 mm
Design
Type	PC

Form factor	Midi Tower

LED indicators	Y

Product colour	Black

Cable management	Y

Supported motherboard form factors	ATX, micro ATX, Mini-ITX

Anti-dust filter	Y

Number of 5.25 bays	2

Number of 3.5 bays	3

Side window	N

Maximum CPU cooler height	16.7 cm

Maximum graphics card length	40 cm

Number of expansion slots	7

Maximum PSU length	20.5 cm

Number of 2.5 bays	2

On/off button	Y
General Information
Marketing Information	The all-black M25-V captivates through its minimalistic, timeless design with mesh front panels and countless features. The elegant look of the case is also reflected within its interior. Clean outside and tidy inside – power supply, hard drives and cables all disappear from view. Systematic Arrangement The special construction of the case interior offers enormous opportunities for discreet installation of various components. Cabling can be inconspicuous and hidden, therefore not affecting airflow inside the case. The power supply and up to three 3.5 hard drives can be installed on the bottom of the case inside the tunnel, therefore not detracting from the appearance. The air vents on the tunnel, side and top, ensure optimal cooling of hard drives. The mainboard and the remaining components enjoy perfect cabling thanks to the cable outlets. Installing a new heat sink for the CPU is extremely easy thanks to an opening in the mainboard tray. A tower cooler up to 16.7 cm in height can be installed. Maximum length for graphics cards is 40 cm; power supplies with a length of up to 20.5 cm. Three pre-installed dust filters protect installed hardware from contamination. For cleaning, they are easily removable and placed back on. Another filter is also pre-installed on the top panel, which can be quickly removed thanks to its magnetic fastener. Cableless Front Panel Design Another big advantage of the M25-V is its cableless front panel design. The front panel can be easily removed without needing to disconnect any cables. This facilitates the installation of a 5.25 or 3.5 drive tremendously. Optimal Preparation for Prefect Airflow The front panel has numerous right and left air inlets, concealed behind the mesh front panel, ensuring a supply of cold air. Also in the front panel, behind the dust filter, a 120 mm fan is pre-installed. Alternatively, matching holes for two 140 mm fans are readily available. For water cooling, the M25-V offers the possibility of a 240 mm or 280 mm radiator, with a total height of 5.0 cm including fan, to be operated in the front of the case. On the rear panel of the case a 120 mm fan is pre-installed. Likewise, if desired, three 120 mm or two 140 mm fans can be installed underneath the magnetic top filter. Oval hole cutouts offer excellent opportunities for perfect positioning of fans or radiators. Modern Front Connectors Two USB 3.0 and two Audio ports in the front panel provide quick access to connect the most important peripheral devices. The USB 3.0 ports are connected via a 19-pin mainboard connector including an alternative USB 2.0 plug, to ensure backward compatibility with older mainboards. Versatile Mounting Options For optical drives, the M25-V provides two 5.25 drive bays with automatically locking tool-free device installation. By means of the enclosed 5.25 to 3.5 bay cover, for example, a card reader can be quickly and easily into one of the two 5.25 drive bays. If necessary, two 2.5 HDD/SSDs can be incorporated instead. If more space is needed, the screwed in drive bays can be completely removed. In the bottom of the case, up to two 3.5 hard drives, or two 2.5 HDD/SSDs decoupled, are installed by means of a mounting frame. Space for another 3.5 drive is also available on the bottom of the case. Behind the mainboard tray of the M25-V, and on the tunnel, are two mounts for 2.5 drive bay trays. Thus allowing, via convenient thumbscrews, installation of up to two 2.5 HDD/SSDs.
Logistics data
Harmonized System (HS) code	84733080
Packaging content
Manual	Y
Ports & interfaces
Audio input	Y

Audio output	Y

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Power supply
Power supply location	Bottom

Power supply included	N
Storage
Supported HDD sizes	2.5,3.5
Weight & dimensions
Weight	6.5 kg

Height	465 mm

Width	210 mm

Depth	450 mm
