CPU
LGA775 socket for latest Intel Pentium 4 / Celeron D processor
FSB 1066/800/533 MHz
Support Hyper-Threading Technology
CHIPSET
SiS® 656 & 965
North Bridge: SiS® 656
South Bridge: SiS® 965
MEMORY
Dual-channel DDR2 memory architecture
4 x 240-pin DDR2 DIMM socket support up to 4 GB
Support DDR2 667/533/400 DDR2 SDRAM
EXPANSION SLOT
2 x PCI Express x16 slots
1 x PCI Express x1 slot
1 Elite Bus slot
3 x PCI slots
STORAGE
Supported by SiS 965
2 x Ultra DMA133/100/66 devices
4 x Serial ATA devices
RAID0, RAID1& RAID 0+1 configuration
Supported by SiI3132
2 x Serial ATAII 3.0Gb/s devices
RAID0, RAID1& e-SATA configuration
AUDIO
Realtek ALC850 8-channel audio CODEC
Compliant with AC'97 2.3 specification
IEEE 1394a
VIA® VT6307, support 2x IEEE1394a ports
LAN
Marvell 88E1111 Giga LAN PHY
REAR PANEL I/O
1 x PS/2 keyboard & PS/2 mouse connectors
4 x USB ports
1 x RJ45 LAN connector
1 x 1394a connector
2 x Serial ports (COM1 & COM2)
1 x Parallel port (LPT)
1 x Audio port (Line-in,4x Line-out, Mic_in)
INTERNAL I/O CONNECTORS & HEADERS
1 x 24-pin ATX Power Supply connector
1 x 4-pin ATX 12V connector
1 x FDD connector supports two 360K~2.88MB FDDs
1 x IrDA for SIR header
1 x Speaker header
1 x 1394a header
2 x USB 2.0 headers support additional 4 USB Ports
6 x Serial ATA connectors
1 x Front panel switch/LED header
1 x Front panel audio header
1 x CD in header
CPUFAN/NB_FAN/SYSFAN/PWR_FAN connectors
SYSTEM BIOS
Award BIOS with 4Mb Flash ROM
Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
Supports ACPI revision 1.0 specification
FORM FACTOR
ATX Size, 305mm*244mm
Виж още Дънни платки за Intel процесори Elitegroup
Виж всички Дънни платки за Intel процесори в категорията
LGA775 socket for latest Intel Pentium 4 / Celeron D processor
FSB 1066/800/533 MHz
Support Hyper-Threading Technology
CHIPSET
SiS® 656 & 965
North Bridge: SiS® 656
South Bridge: SiS® 965
MEMORY
Dual-channel DDR2 memory architecture
4 x 240-pin DDR2 DIMM socket support up to 4 GB
Support DDR2 667/533/400 DDR2 SDRAM
EXPANSION SLOT
2 x PCI Express x16 slots
1 x PCI Express x1 slot
1 Elite Bus slot
3 x PCI slots
STORAGE
Supported by SiS 965
2 x Ultra DMA133/100/66 devices
4 x Serial ATA devices
RAID0, RAID1& RAID 0+1 configuration
Supported by SiI3132
2 x Serial ATAII 3.0Gb/s devices
RAID0, RAID1& e-SATA configuration
AUDIO
Realtek ALC850 8-channel audio CODEC
Compliant with AC'97 2.3 specification
IEEE 1394a
VIA® VT6307, support 2x IEEE1394a ports
LAN
Marvell 88E1111 Giga LAN PHY
REAR PANEL I/O
1 x PS/2 keyboard & PS/2 mouse connectors
4 x USB ports
1 x RJ45 LAN connector
1 x 1394a connector
2 x Serial ports (COM1 & COM2)
1 x Parallel port (LPT)
1 x Audio port (Line-in,4x Line-out, Mic_in)
INTERNAL I/O CONNECTORS & HEADERS
1 x 24-pin ATX Power Supply connector
1 x 4-pin ATX 12V connector
1 x FDD connector supports two 360K~2.88MB FDDs
1 x IrDA for SIR header
1 x Speaker header
1 x 1394a header
2 x USB 2.0 headers support additional 4 USB Ports
6 x Serial ATA connectors
1 x Front panel switch/LED header
1 x Front panel audio header
1 x CD in header
CPUFAN/NB_FAN/SYSFAN/PWR_FAN connectors
SYSTEM BIOS
Award BIOS with 4Mb Flash ROM
Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
Supports ACPI revision 1.0 specification
FORM FACTOR
ATX Size, 305mm*244mm
Виж още Дънни платки за Intel процесори Elitegroup
Виж всички Дънни платки за Intel процесори в категорията
