CPU
LGA775 socket for latest Intel® Core 2 Quad(95W)/Core 2 Duo /Celeron D 400 series processor
FSB 1333/1066/800 MHz
CHIPSET
Intel® G33 & ICH9
North Bridge: Intel® G33
South Bridge: Intel® ICH9
GRAPHICS
Integrated Intel® Graphics Media Accelerator 3100 (GMA3100)
MEMORY
Dual-channel DDR2 memory architecture
4 x 240-pin DDR2 DIMM socket support up to 8 GB
Support DDR2 800/667 DDR SDRAM
EXPANSION SLOT
1 x PCI Express x16 slot
1 x PCI Express x1 slot
2 x PCI slots
STORAGE
Support by Intel® ICH9
4 x Serial ATAII 3.0Gb/s devices
AUDIO
Realtek ALC883 support 8-ch HD Audio
LAN
Realtek GigaLAN 8111B (Realtek 10/100 LAN 8101E optional)
REAR PANEL I/O
1 x PS/2 keyboard & PS/2 mouse connectors
4 x USB ports
1 x VGA port
1 x Serial port (COM1)
1 x Parallel port (LPT1) (Optional)
1 x 1394a port(optional)
1 x RJ45 LAN connector
1 x Audio port
INTERNAL I/O CONNECTORS & HEADERS
1 x 24-pin ATX Power Supply connector
1 x 4-pin ATX 12V connector
1 x FDD connector supports two 360K~2.88MB FDDs
4 x Serial ATA connectors
1 x COM2 header (optional)
4 x USB 2.0 headers support additional 8 USB ports
1 x 1394a header(optional)
1 x Clear CMOS header
1 x Front panel header
1 x Front panel audio header
1 x CD in header
CPUFAN/SYSFAN connectors
SYSTEM BIOS
AMI BIOS with 8Mb SPI ROM
Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
Supports ACPI revision 1.0 specification
FORM FACTOR
Micro-ATX Size, 244mm*244mm
