Technical Specifications
Brightness
2,100 ANSI Lumens (Max)
Light Valve
Single-chip 0.55" XGA DDR (Double Data Rate) technology
Contrast Ratio
2000:1 Typical (Full On / Full Off)
Lamp
200 Watt user replaceable
Resolution
Native XGA (1024 x 768), with autosync up to UXGA (1600 x 1200)
Displayable Color
16.7M
Projection Lens
F/2.35 - 2.47, f = 21.83 - 23.81 mm, 1.1x manual zoom lens
Projection Screen Size
Diagonal 34.7 - 304.9 inches (88.1 - 774.4 cm)
Projection Distance
4.9 - 39.4 ft (1.5 - 12 m)
Video Compatibility
NTSC 3.58, NTSC 4.43, PAL, PAL-M, PAL-N, SECAM and HDTV (480i; 480P; 576i; 576P; 720P; 1080i)
Composite Video, Component Video and S-Video Capability
H. Frequency
15kHz - 94kHz (Analog)
V. Frequency
50Hz - 85Hz (Analog)
Audio
1 Speaker, 2W side-mounted
Power Supply
Universal 100 - 240V AC 50-60Hz
Power Consumption
255 Watts (Typical) / 190 Watts (Eco Mode)
Noise Output
36 dB(A) Full-on mode / 30 dB(A) Eco Mode
I/O Connectors
Power: AC power input socket
VGA Input: Two 15-pins VGA connectors (Blue), 'VGA-A In & VGA-B In', for analog RGB/Component, HDTV input signals
VGA Output: One 15-pins VGA connector (Black) for 'VGA-A Out' loop through
Video Input: One S-Video, one Composite Video (RCA-Yellow)
Audio Input: One 3.5 mm stereo mini phone jack (Blue)
Audio output: One 3.5 mm stereo mini phone jack (Green)
RS-232 port: One mini-DIN 6-pins
USB port: One USB slave for remote mouse support
Weight
4.6 lbs (2.1 kg)
Dimensions (W x H x D)
9.6 x 8.3 x 4.5 inches (244 x 211 x 115 mm)
Environmental
Operating Temperature: 41ºF - 95ºF (5ºC - 35ºC)
Storage Temperature: -4ºF - 140ºF (-20ºC - 60ºC)
Humidity: 80% max
