ASUS TUF GAMING A520M-PLUS

[Graphics]: 1 x D-Sub; 1 x DVI-D; 1 x HDMI 2.1(4K@60HZ)

[CPU's supported]: AMD AM4 Socket for AMD Ryzen™ 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors *

[Chipset]: AMD A520

[Expansion Slots]: AMD Ryzen™ 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors; 1 x PCIe 3.0 x16 (x16 mode); AMD A520 Chipset; 2 x PCIe 3.0 x1

[Storage]: Total supports 1 x M.2 slot(s) and 4 x SATA 6Gb/s ports; AMD Ryzen™ 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors : 1 x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes) storage devices support; AMD A520 Chipset : 4 x SATA 6Gb/s port(s),; Support Raid 0, 1, 10

[Memory type]: 4 x DIMM, Max. 128GB, DDR4 4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz Un-buffered Memory *; Dual Channel Memory Architecture; ECC Memory (ECC mode) support varies by CPU.

[I/O]: 1 x PS/2 keyboard/mouse combo port(s); 1 x DVI-D; 1 x D-Sub; 1 x HDMI; 1 x LAN (RJ45) port(s); 1 x USB 3.2 Gen 2 (teal blue)Type-A,; 4 x USB 3.2 Gen 1 (blue) Type-A; 2 x USB 2.0; 3 x Audio jack(s)

[Connectors]: 1 x CPU Fan connector(s); 2 x Chassis Fan connector(s); 1 x Aura RGB Strip Header; 1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s); 2 x USB 2.0 connector(s) support(s) additional 3 USB 2.0 port(s); 1 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode); 1 x M.2 with E key for Wi-Fi module; 1 x SPI TPM header; 4 x SATA 6Gb/s connector(s); 1 x S/PDIF out header(s); 1 x 24-pin EATX Power connector(s); 1 x 8-pin EATX 12V Power connectors; 1 x Front panel audio connector(s) (AAFP); 1 x Clear CMOS jumper(s); 1 x System panel connector; 1 x COM port header

[Audio]: Realtek ALC887/897 7.1 Surround Sound High Definition Audio CODEC ; - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback; Audio Feature : - Audio Shielding; - Dedicated audio PCB layers; - Premium Japanese audio capacitors

[LAN]: Realtek L8200A 1Gb Ethernet ,TUF LANGuard

[BIOS]: 256 Mb Flash ROM, UEFI AMI BIOS

[Form Factor]: mATX Form Factor; 9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )

[OS]: Windows® 10 64-bit

[Other]: M.2 slot only (Key E) (Support PCIe interface)* *Wi-Fi module is sold separately.

[Warranty]: 36 Months
