Водно охлаждане за процесор Fractal Design Lumen S24 V2, съвместимост със сокети LGA 1700/1150/1151/1155/1156/1200/1366/2011/2011-3/2066 & AMD AM5/AM4/FM2+/FM2/ FM1/AM3+/AM3/AM2+/AM2

	The right way up The removable top can be turned at 90-degree intervals, making the logotype horizontal independent of the mounting orientation Low-permeability rubber tubes with braided nylon sleeves
From subtle to stunning Duality design provides both a stealthy and illuminated look, controlled from your motherboard RGB UI Six ARGB LEDs are yours to command via your motherboard or controller
	Forget the thermal paste Thermal paste is pre-applied to ensure a proper and pain-free installation Articulating elbow fittings make tubes easier to route and reduces tension on the cold plate housing

Technical specifications

General specifications

Sockets supported (Intel)

LGA 1700*/1150/1151/1155/1156/1200 LGA 1366/2011/2011-3/2066

Sockets supported (AMD)

AM5 / AM4/FM2+/FM2/ FM1/AM3+/AM3/AM2+/AM2

*Compatible using updated LGA 1700 bracket, contact Fractal support to request one if using an older version

Cold plate material

Copper

Thermal paste

Pre-applied

Tube length

400mm

Tube material

Low-permeability rubber with braided nylon sleeve

Fittings, block side

Articulating 90-degree Elbow

Fittings, radiator side

Barbed fitting

Block height

43mm

Block measurements (with fittings)

79 x 67 mm

Block diameter (main block body)

67 mm

Fan specifications

Fan type

Aspect 12 PWM

Rotational speed

500–2000 RPM

Fan bearing

Rifle bearings

Fan PWM control

Yes

Fan acoustical noise

<10–33.2 dBA

Fan maximum air flow

13-56 CFM

Fan maximum static pressure

0.230–2.34 mm H2O

Fan input voltage

12V

Fan maximum input current

0.37A

Fan MTTF

90,000 hours

Pump specifications

Rotational speed

4000 ± 10% RPM

Bearing type

Ceramic

PWM control

No

Acoustical noise (full speed)

22 dBA

Maximum pressure

1.8 mm H2O/ 17.6 kPa / 2.5 PSI

Input voltage

12V DC

Input current (without fans)

0.34 A

MTTF

50 000 hours

Radiator specifications

Radiator dimensions

272 x 120 x 27 mm

Radiator housing material

Aluminum

Radiator fin material

Aluminum

Radiator fan screw threads

6-32
