Термопад Arctic TP-4, размер 100mm x 100mm, дебелина 0.5mm

High Performance — Extremely Soft
The silicone-based TP-4 combines high thermal conductivity with extremely low hardness and reliably compensates for manufacturing tolerances between chips.

Safe Application
Electrically insulating, non-adhesive, and easy to handle — for safe and reliable heat transfer.

Minimizing Thermal Resistance
The thinner the pad, the lower the thermal resistance. Depending on mounting pressure, the TP-4 can be compressed to up to 60% of its original thickness.

Bridging Uneven Surfaces
Adapts optimally to varying chip heights, air gaps, and uneven surfaces to ensure reliable contact.


Specifications

Operating Ambient Temperature
-40-200 °C

Dimensions
100 (L) x 100 (W) x 0.5 (H) mm

Hardness
50 Shore OO

Specific Gravity
3.4 g/cm³

Breakdown Voltage
8620 V/mil

Dielectric Constant
7.2 @1 MHz

Volume Resistance
1.52 x 10^13 Ω-cm

Flammability Rating
UL 94 V-0
