Дънна платка Sapphire NITRO+ B850A WIFI 7, B850, AM5, DDR5, PCI-E 5.0 (DP&HDMI), 4x SATA 6Gb/s, 3x M.2, 1x USB 3.2 Gen 2 Type-C, Bluetooth 5.4, ATX

Specifications

Chipset

AMD B850

CPU Support

Supports AMD Socket AM5 Processors including Ryzen 9000 / 8000 / 7000 Series Desktop Processors

Memory Support

4x DIMMS, Dual Channel DDR5, Maximum Memory Capacity 256GB (4x 64GB), up to 8000 MHz(OC)

PCI-E Expansion Slots

1x PCIe 5.0 x16, 1x PCIe 4.0 x4 in 16x slot, 1x PCIe 4.0 x2 in 16x slot

Display Connector

DisplayPort x1, HDMI x1

Audio

Realtek ALC897 HD Audio, 7.1 Channel

Network

Realtek RTL8125BG 2.5 Gigabit Ethernet
M.2 WiFi 7 Module, Support 802.11 a/b/g/n/ac/ax/be, 2.4 GHz / 5GHz / 6GHz band, Bluetooth 5.4 Support

Front USB Headers

1x USB 3.2 Gen1 (1 x Type C), 1x USB 3.2 Gen1 (2 x Type A), 1x USB 2.0 (2 x Type A)

Rear Ports

1 × DisplayPort, 1 × HDMI, 1 × RJ45 LAN, 2 × Wi Fi Antenna
One-click Flash BIOS Button, 4 × USB 2.0, 3 × USB 3.2 Gen2 Type A
1 × USB 3.2 Gen2 Type C, 6 × Audio Jacks

Storage

1x PCIe 5.0 M.2, 2x PCIe 4.0 M.2, 4x SATA

Dimensions

ATX, 305x244mm

Debug LED

DRAM: Yellow, CPU: Red, GPU: White, Boot: Green
