| Design | ||
|---|---|---|
| Chassis type | SFF | |
| Cable lock slot | Yes | |
| Product colour | Black | |
| Placement supported | Vertical | |
| Volume | 8.2 L | |
| Cable lock slot type | Kensington | |
| Colour name | Black | |
| Graphics | ||
| On-board graphics card model | Intel UHD Graphics 770 | |
| Discrete graphics card model | Not available | |
| On-board graphics card | Yes | |
| Discrete graphics card | No | |
| On-board graphics card family | Intel® UHD Graphics | |
| On-board GPU manufacturer | Intel | |
| Memory | ||
| Internal memory type | DDR4-SDRAM | |
| Memory slots | 4x DIMM | |
| Maximum internal memory | 128 GB | |
| Memory clock speed | 3200 MHz | |
| Memory channels | Dual-channel | |
| Memory layout (slots x size) | 1 x 16 GB | |
| Internal memory | 16 GB | |
| Network | ||
| Wi-Fi standards | Wi-Fi 6E (802.11ax) | |
| Cabling technology | 10/100/1000Base-T(X) | |
| Bluetooth version | 5.1 | |
| Ethernet LAN | Yes | |
| Antenna type | 2x2 | |
| Bluetooth | Yes | |
| Wi-Fi | Yes | |
| Ethernet LAN data rates | 100,1000 Mbit/s | |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) | |
| WLAN controller model | Intel Wi-Fi 6E AX211 | |
| WLAN controller manufacturer | Intel | |
| Operational conditions | ||
| Operating altitude | 0 - 3048 m | |
| Operating relative humidity (H-H) | 20 - 80% | |
| Storage temperature (T-T) | -40 - 60 °C | |
| Operating temperature (T-T) | 5 - 35 °C | |
| Storage relative humidity (H-H) | 10 - 90% | |
| Non-operating altitude | 0 - 12192 m | |
| Packaging content | ||
| Display included | No | |
| Mouse included | Yes | |
| Keyboard included | Yes | |
| Mouse connectivity | Wired | |
| Keyboard connectivity | Wired | |
| Performance | ||
| Motherboard chipset | Intel Q670 | |
| Audio system | High Definition Audio | |
| Built-in speaker(s) | Yes | |
| Trusted Platform Module (TPM) | Yes | |
| Password protection type | HDD, Power on, Supervisor | |
| Number of speakers | 1 | |
| Product type | PC | |
| Password protection | Yes | |
| Audio chip | Realtek ALC897Q-CG | |
| Ports & interfaces | ||
| Line-out | Yes | |
| USB 2.0 ports quantity | 4 | |
| Ethernet LAN (RJ-45) ports | 1 | |
| Microphone in | Yes | |
| HDMI ports quantity | 1 | |
| HDMI version | 2.1 | |
| DisplayPorts quantity | 2 | |
| Combo headphone/mic port | Yes | |
| DisplayPort version | 1.4a | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 | |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 | |
| Power | ||
| Power supply | 260 W | |
| Power supply input voltage | 100 - 240 V | |
| Power supply input frequency | 50/60 Hz | |
| Processor | ||
| Processor model | i7-13700 | |
| Number of processors installed | 1 | |
| Processor manufacturer | Intel | |
| Processor family | Intel® Core™ i7 | |
| Processor cores | 16 | |
| Processor threads | 24 | |
| Processor boost frequency | 5.2 GHz | |
| Processor cache | 30 MB | |
| Processor cache type | Smart Cache | |
| Efficient cores | 8 | |
| Performance cores | 8 | |
| Processor base power | 65 W | |
| Maximum turbo power | 219 W | |
| Efficient-core base frequency | 1.5 GHz | |
| Performance-core base frequency | 2.1 GHz | |
| Processor generation | 13th gen Intel® Core™ i7 | |
| Efficient-core Max Turbo Frequency | 4.1 GHz | |
| Performance-core Max Turbo Frequency | 5.1 GHz | |
| Software | ||
| Operating system installed | Windows 11 Pro | |
| Operating system architecture | 64-bit | |
| Operating system language | German | |
| Storage | ||
| Compatible memory cards | SD, SDHC, SDXC | |
| Optical drive type | DVD±RW | |
| Total storage capacity | 512 GB | |
| Card reader integrated | Yes | |
| SSD interface | PCI Express 4.0 | |
| SSD capacity | 512 GB | |
| Number of SSDs installed | 1 | |
| Storage media | SSD | |
| SSD form factor | M.2 | |
| NVMe | Yes | |
| Total SSDs capacity | 512 GB | |
| Sustainability | ||
| Sustainability certificates | TCO, RoHS | |
| Weight & dimensions | ||
| Weight | 5.3 kg | |
| Height | 339.5 mm | |
| Width | 92.5 mm | |
| Depth | 297.7 mm | |
