Product benefits
- Stylish and modern design
- Easy to install and use
- Highly versatile due to selectable CCT
- Long lifetime thanks to LED technology
Areas of application
- Indoor
- Living areas (living rooms, dining rooms, bedrooms etc.)
- Bathrooms (IP44)
Product features
- Type of protection: IP44
- Lifetime up to 30,000 h
- Color temperature: 3,000 K (Warm White) or 4,000 K (Neutral White)
- Click-CCT version: color temperature adjustable in two steps by repeated switching
- Housing material: aluminum
- Glass diffuser
Safety advice
- Luminaire must be disconnected from mains during installation, maintenance and cover removal
- Check wall-ceiling for suitability. If uncertain, seek professional advice.
- All electrical connections must be made by a qualified person.
- Caution, risk of electric shock.
Technical data
Electrical data
Nominal wattage | 11.00 W |
Nominal voltage | 220…240 V |
Mains frequency | 50…60 Hz |
Nominal current | 63.000 mA |
Inrush current | 0.063 A |
Inrush current time Th50 | 192 µs |
Max. number of luminaires per miniature circuit breaker B16 | 203 |
Max. number of luminaires per miniature circuit breaker C10 | 126 |
Max. number of luminaires per miniature circuit breaker C16 | 203 |
Power factor λ | > 0.5 |
Total harmonic distortion | 68 % |
Protection class | II |
Operating mode | External LED driver |
Photometrical data
Luminous flux | 700 lm |
Total luminous flux of contained light sources | 870 lm |
Luminous efficacy | 64 lm/W |
Color temperature | 3000 … 4000 K |
Reference control setting of contained light source (Kelvin) | 3000 K |
Light color (designation) | Warm White, Cool White |
Color rendering index Ra | > 80 |
Standard deviation of color matching | ≤6 sdcm |
Flickering metric (Pst LM) | ≤1.0 |
Stroboscope effect metric (SVM) | ≤0.4 |
Photobiological safety group acc. to EN62778 | RG0 |
Photobiological safety group acc. to EN62471 | RG0 |
Beam angle | 115 ° |
Dimensions & Weight
Length | 300.00 mm |
Height | 90.00 mm |
Width | 130.00 mm |
Product weight | 550.00 g |
Materials & Colors
Product color | Chrome |
Housing color | Chrome |
Body material | Metal|Glass |
Cover material | Polycarbonate (PC) |
Glow Wire Test according to IEC 60695-2-12 | 650 °C |
Mercury content | 0.0 mg |
Application & Mounting
Ambient temperature range | -20…+40 °C |
Temperature range at storage | -20…+80 °C |
Type of connection | Terminal, 2-Pole (L, N) |
Type of protection | IP44 |
Protection class IK (shock resistance) | IK03 |
Dimmable | No |
Mounting type | Surface |
Mounting location | Wall |
Application environment | Indoor |
With light source | Yes |
Replaceable light source | No |
Lifespan
Lifespan L70/B50 at 25 °C | 30000 h 1) |
Number of switching cycles | 15000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
Certificates & Standards
Standards | CE, UKCA |
Luminaire with limited surface temperature, "D sign" | No |
Replaceable light source (EPREL) | Not replaceable |
PRODUCT SHEET
Quantity of precious metals | Contains at least 10 mg |
Quantity of rare earths | Contains at least 1 mg |
Виж още LED Жилищно осветление Ledvance
Виж всички LED Жилищно осветление в категорията
Технически характеристики
Тип: | Аплик |
---|---|
Монтаж: | Стена |
Влагозащитеност: | IP44 (Външна употреба) |
Мощност: | 11 W |
Напрежение: | 240 V |
Светлинен поток: | 700 lm |
Цветна температура: | Неутрално бяла (4000K) |
Цвят на корпуса: | Сив |
Особеност: | Няма |
