Efficient cooling:
The FF01 series of standalone server racks from Lanberg is the ideal solution for those looking for performance even in the most demanding temperature conditions. Our rack cabinets combine optimal performance with functionality, aesthetics and security.
Thanks to the ventilation hole at the top of the design, each of our cabinets provides excellent airflow, which translates into effective cooling. This element, combined with built-in fans, guarantees temperature control inside the cabinet, which is key to maintaining optimal operating conditions for your equipment.
The design of our FF01 server cabinets has been thoughtfully considered to ensure the highest cooling efficiency. This translates into long-lasting and trouble-free operation of your equipment, regardless of its requirements.
Specifications
Type of cabinet
Free standing
Size
19"
ICT height
22 U
Assembly type
Self-assembly
Working depth
860 mm
Front door type
Perforation
Rear door type
Perforation
Door type
Single-leaf
Maximum front door opening angle
215 °
Maximum static load
1200 kg
Slot amount for fans
6
Number of vertical rails
4
Thermostat
Yes
LCD panel
Yes
Colour
Black
RAL color
RAL9004
Weatherproof rating
IP20
Front door thickness
1.2 mm
Rear door thickness
1.2 mm
Upper & lower panel thickness
1.5 mm
Side panel thickness
1.2 mm
Mounting rails thickness
2 mm
Frame thickness
1.5 mm
Other elements sheet thickness
1.2 mm
Depth
1000 mm
Width
800 mm
Height
1239 mm
Height without casters
1132 mm
Weight
104 kg
Standard
ANSI/EIA RS-310-D, DIN 41491/PART 1, DIN 41494/PART 7, ETSI, IEC297-2:1982
Grounding Details
Back door, Frame, Front door
