Kingston FURY Beast
DESCRIPTION
Kingston FURY KF552C36BBEAK2-64 is a kit of two 4G x 64-bit
(32GB) DDR5-5200 CL36 SDRAM (Synchronous DRAM) 2Rx8,
memory module, based on sixteen 2G x 8-bit FBGA components per
module. Each module kit supports AMD® EXPO v1.0 and
Intel® Extreme Memory Profiles (Intel® XMP) 3.0. Total kit
capacity is 64GB. Each module has been tested to run at
DDR5-5200 at a low latency timing of 36-38-38 at 1.25V. The
SPDs are programmed to JEDEC standard latency
DDR5-4800 timing of 40-39-39 at 1.1V. Each 288-pin DIMM
uses gold contact fingers. The JEDEC standard electrical
and mechanical specifications are as follows:
SPECIFICATIONS
| CL(IDD) | 40 cycles |
| Row Cycle Time (tRCmin) | 48ns(min.) |
| Refresh to Active/Refresh Command Time (tRFCmin) |
295ns(min.) |
| Row Active Time (tRASmin) | 32ns(min.) |
| UL Rating | 94 V - 0 |
| Operating Temperature | 0 C to +85 C |
| -55 C to +100 C |
FEATURES
- Power Supply: VDD = 1.1V Typical
- VDDQ = 1.1V Typical
- VPP = 1.8V Typical
- VDDSPD = 1.8V to 2.0V
- On-Die ECC
- Height 1.66” (42.23mm), w/heatsink
FACTORY TIMING PARAMETERS
- Default (JEDEC): DDR5-4800 CL40-39-39 @1.1V
- EXPO Profile #0: DDR5-5200 CL36-38-38 @1.25V
- EXPO Profile #1: DDR5-4800 CL38-38-38 @1.1V
- XMP Profile #1: DDR5-5200 CL36-38-38 @1.25V
- XMP Profile #2: DDR5-4800 CL38-38-38 @1.1V
Виж още Настолни компютри Памети Kingston
Виж всички Настолни компютри Памети в категорията
KF552C36BBEAK2-64 datasheet| Капацитет: | 64 (2x32) GB |
|---|---|
| Скорост: | 5200 MT/s |
| Тип: | DDR5 |
