Система за измерване Growatt SPM-E Smart Meter Device, 1P2W, 10A/100A, IP51, RS485

Growatt SPM-E Smart Meter Device

Power grid type: 1P2W, Input voltage: 184 Vac ~ 276 Vac (L-N)

Frequency: 50/60Hz (45~56)Hz, Normal current/Max. current: 10A/100A

Voltage/Current Accuracy: 0.5 %, Power Accuracy: 1 %, Frequency Accuracy: 0.2 %

Interface: RS485, Baud rate: 9600, Communication protocol: Modbus-RTU

Environment protection rating: IP51, Operating temperature range: -25 °C to 55 °C,

Storage temperature range: -40 °C to 70 °C, Operating humidity: 0 - 90% (non-condensing)

Mounting type: DIN rail 35mm; Dimensions (W x H x D): 36 x 63 x 99 mm, Weight: 223 g
