VIGI Solar System Controller
- 31.2Ah/10.8V Automotive-Grade Lithium Battery
- Remote Management and Maintenance via the VIG app or VIGI Cloud VMS
- Intelligent Auxiliary Heating Technology Ensures Optimal Battery Performance in Extreme Cold Weather
- Maximum Power Point Tracking (MPPT) Charging Controller Increases Charging Efficiency by 20%*
- Over-charge, Over-discharge, Over-current, Overheat, and Short-circuit Protections
- Remaining Capacity > 70%** after 500 Cycles
- IP66 Weatherproof
| Category | Specification |
|---|---|
| Battery | |
| Type | Lithium |
| Intelligent Auxiliary Heat | Yes |
| Battery Capacity | 31.2 Ah |
| Voltage | 10.8 V |
| Max. Output Voltage | 12.6 V |
| Life | More than 500 cycles△ |
| Dimension | 242×70×65 mm (9.5×2.8×2.6 in) |
| Charging Condition | • 0°C45°C• -30°C45°C (With intelligent auxiliary heating) |
| Discharging Condition | • -20°C60°C• -30°C60°C (With intelligent auxiliary heating) |
| Hardware | |
| Interface | • 1× 10/100 Mbps RJ45• 1× Photovoltaic Panel Connector• 3× 5.5mm DC Power Plugs (#1, #2: 9V-12.6 VDC/2A, #3: 12 VDC/2A) |
| Indicator LED | • Quantity: 4 (SYS, LAN, PV, BAT Indicators)• Color: Blue |
| Software Features | |
| Load Control | Yes |
| High and Low Temp Protection | Yes |
| Overdischarge Protection | Yes |
| Power Consumption Statistics | Yes |
| Real-time Load Status Display | Yes |
| Battery Level Display | Yes |
| Time Zone Selection | Yes |
| Region Selection | Yes |
| Schedule Saving | Yes |
| Firmware Remote Update | Yes |
| Remote Reboot | Yes |
| Local LAN Management | Yes |
| Intelligent Aux Heat Control | -30°C~5°C |
| Smart Charging Control | -30°C~5°C |
| Account Management | Yes |
| Remote Reset | Yes |
| Remote Message Push | Yes |
| Other | |
| Certifications | • CB, PSE (Battery)• CE, FCC, VCCI, IC, IP66 Weatherproof |
| Box Dimensions (W×D×H) | 580×320×225 mm (22.83×12.60×8.86 in) |
| Weight | Package Weight: 9.9 kg |
Виж още Модули за фотоволтаици TP-Link
Виж всички Модули за фотоволтаици в категорията
Технически характеристики
| Тип: | Контролер |
|---|
