TP-Link VIGI PS20

  • 20.8Ah/10.8V Automotive-Grade Lithium Battery
  • Remote Management and Maintenance via the VIG app or VIGI Cloud VMS
  • Intelligent Auxiliary Heating Technology Ensures Optimal Battery Performance in Extreme Cold Weather
  • Maximum Power Point Tracking (MPPT) Charging Controller Increases Charging Efficiency by 20%*
  • Over-charge, Over-discharge, Over-current, Overheat, and Short-circuit Protections
  • Remaining Capacity > 70%** after 500 Cycles
  • IP66 Weatherproof​​​​​​​



CategorySpecification
Battery
TypeLithium
Intelligent Auxiliary HeatYes
Battery Capacity20.8 Ah
Voltage10.8 V
Max. Output Voltage12.6 V
LifeMore than 500 cycles△
Dimension242×70×55 mm (9.5×2.8×2.2 in)
Charging Condition• 0°C45°C• -30°C45°C (With intelligent auxiliary heating)
Discharging Condition• -20°C60°C• -30°C60°C (With intelligent auxiliary heating)
Hardware
Interface• 1× 10/100 Mbps RJ45• 1× Photovoltaic Panel Connector• 3× 5.5mm DC Power Plugs (#1, #2: 9V-12.6 VDC/2A, #3: 12 VDC/2A)
Indicator LED• Quantity: 4 (SYS, LAN, PV, BAT)• Color: Blue
Software Features
Load ControlYes
High and Low Temp ProtectionYes
Overdischarge ProtectionYes
Power Consumption StatsYes
Displays Load StatusYes
Battery Level DisplayYes
Time Zone SelectionYes
Region SelectionYes
Schedule SavingYes
Firmware Remote UpdateYes
Remote RebootYes
Local LAN ManagementYes
Intelligent Aux Heat Ctrl-30°C~5°C
Smart Charging Control-30°C~5°C
Account ManagementYes
Remote ResetYes
Remote Message PushYes
Other
Certifications• CB, PSE (Battery)• CE, FCC, VCCI, IC, IP66 Weatherproof
Package Contents• VIGI Solar System Controller• Quick Start Guide• Waterproof Cable Attachments• Mounting Accessories
Package Dimensions (W×D×H)580×320×225 mm (22.83×12.60×8.86 in)
Package Weight9.2 kg
