Chieftec EON ZPU-600S
The EON Series offers high quality and 80 PLUS® 230V EU efficiency at highly
competitive pricing, equipped with silent 120mm fans.
The power supplies are fully built from steel, coated in elegant black, and
equipped with extra-long native cables. The EON Series runs quietly and provides
its power with all essential protection and safety features.
Specifications:
| Weight (without/with package) | 1.34kg / 1.62kg |
|---|---|
| AC Input | 200-240V / 4.5A |
| Frequency | 50Hz |
| +5V | 20A |
| +3.3V | 20A |
| +5V & +3.3V combined | 100W |
| +12V1 | 45A |
| +12V2 | -- |
| +12V1, +12V2 combined | 540W |
| P.F. | >0.9 |
| -12V | 0.4A / 4.8W |
| +5VSB | 2.5A / 12.5W |
| Maximum Power | 600W |
| 20+4 PIN ATX | 1 |
|---|---|
| 8 PIN EPS (4+4) | 2 |
| 8 PIN PCIe (6+2) | 2 |
| SATA | 4 |
| MOLEX/FLOPPY | 2 |
| 20+4 PIN ATX | 650 |
|---|---|
| 8 PIN EPS (4+4) | 700/100 |
| 8 PIN PCIe (6+2) | 550/150 |
| SATA | 450/150/150 |
| MOLEX/FLOPPY | 450/150/150 |
| ATX12V Version | ATX 12V 2.3 |
|---|---|
| Efficiency | 80 PLUS® 230V EU |
| Dimension (DxWxH) | 140mm x 150mm x 86mm |
| PFC | Active PFC (0.9) (only 230V) |
| Fan | 120mm silent fan |
JAR Computers може да предложи ремонт/смяна/монтаж в наш сервиз или при партньор.
Виж още Захранвания Настолни компютри Chieftec
Виж всички Захранвания Настолни компютри в категорията
Документация
Datasheet-Eon Series ZPU-600S EN.pdfТехнически характеристики
| Изходна мощност: | 600 W |
|---|---|
| Модулен блок: | Не |
| Форм фактор: | ATX |
