Name: Barebone сървър SuperMicro Universal Server SYS-421GE-TNRT3, up to 2x 5th Gen Intel Xeon Scalable, 32x DDR5, без твърд диск, 2x 10GbE RJ45, без ОС, 4x 2700W PSU, 4U
Brand: Supermicro
SKU: BRBSRSUPERMICROSYS421GETNRT3
Price: 7081.75 EUR
Availability: InStock

Описание Характеристики Ревюта / Въпроси

GPU SuperServer SYS-421GE-TNRT3

Key Applications

High Performance Computing
VDI
AI/Deep Learning Training
Media/Video Streaming
Cloud Gaming
Animation and Modeling
Design & Visualization
3D Rendering
Diagnostic Imaging

Key Features

5th/4th Gen Intel® Xeon® Scalable processor support
32 DIMM slots Up to 8TB: 32x 256 GB DRAM Memory Type: 5600MTs ECC DDR5
AIOM/OCP 3.0 Support
8 PCIe Gen 5.0 X16 FHFL Slots
8x 2.5" Hot-swap SATA drive bays
4x2.5" Hot-swap NVMe drive bays
8 HOT SWAP 2.5” SATA/SAS (AOC required)
8 Hot-Swap Heavy Duty Fans with Optimal Fan Speed Control
4x 2700W (2+2) Redundant Power Supplies, Titanium Level

Category	Specification
Motherboard Model	Super X13DEG-OA
CPU Socket	Dual Socket E (LGA-4677)
Processor Support	5th Gen Intel Xeon Scalable / 4th Gen Intel Xeon Scalable
CPU Core Support	Up to 64 cores / 128 threads per CPU
CPU Cache	Up to 320 MB cache per CPU
CPU TDP Support	Up to 350W (Air cooled), up to 385W (Liquid cooled)
Chipset	Intel C741
GPU Support (Max Count)	Up to 8 double-width or 8 single-width GPUs
Supported GPUs	NVIDIA H100, H100 NVL, A100, L4, L40S, RTX 5000, RTX 6000 Ada, RTX A4000
CPU–GPU Interconnect	PCIe 5.0 x16
GPU–GPU Interconnect	NVIDIA NVLink Bridge (optional)
Memory Slots	32 DIMM slots
Max Memory (1DPC)	Up to 4 TB DDR5 ECC RDIMM @ 5600 MT/s
Max Memory (2DPC)	Up to 8 TB DDR5 ECC RDIMM @ 4400 MT/s
Memory Voltage	1.1V
Network	2 × 10GbE RJ45 (Intel X710-AT2)
Video Output	1 × VGA
BIOS	AMI 32MB SPI Flash EEPROM
Management Software	SuperCloud Composer, SSM, SUM, SuperDoctor 5, SDO, TAS, SAA
Power Management	AC Power Recovery, ACPI Power Management
Security Hardware	TPM 2.0, Silicon Root of Trust (NIST 800-193)
Security Features	Secure Boot, Signed Firmware, Secure Updates, Firmware Recovery, Remote Attestation, Runtime BMC Protection, System Lockdown
PC Health Monitoring	CPU voltage monitoring, memory monitoring, chipset monitoring
Fan Monitoring	Tachometer monitoring, PWM connectors, speed status monitoring
Temperature Monitoring	CPU & chassis temperature monitoring, fan thermal control
Chassis Model	CSE-418G2TS-R5K40P
Chassis Form Factor	4U Rackmount
Dimensions (H × W × D)	7" × 17.2" × 29" (178 × 437 × 737 mm)
Package Dimensions	26.57" × 27" × 41"
Weight (Net)	65.5 lbs (29.7 kg)
Weight (Gross)	100 lbs (45.3 kg)
Chassis Color	Black front, Silver body
Front Panel Buttons	Power On/Off, System Reset
Front Panel LEDs	HDD Activity, Network Activity, Power Status, Overheat & Power Fail
Expansion Slots	8 × PCIe 5.0 x16 FHFL slots
Drive Bays	12 total front hot-swap bays (4 × 2.5" NVMe + 8 × 2.5" SATA)
M.2 Slots	2 × M.2 NVMe (M-Key)
Cooling Fans	Up to 8 heavy-duty fans with speed control
Liquid Cooling	Direct-to-Chip (D2C) cold plate (optional)
Power Supply	4 × 2700W redundant Titanium (96% efficiency)
PSU Input	200–240Vac or 240Vdc (CQC)
+12V Output	Max 225A
12V Standby Output	3.5A–4A
PSU Output Type	Backplane (gold finger)
