Name: Barebone сървър SuperMicro Universal Server SYS-421GE-TNRT, up to 2x 5th / 4th Gen Gen Intel Xeon Scalable, 32x DDR5, без твърд диск, 2x 10GbE RJ45, без ОС, 4x 2700W PSU, 4U
Brand: Supermicro
SKU: BRBSRSUPERMICROSYS421GETNRT
Price: 9181.01 EUR
Availability: InStock

Описание Характеристики Ревюта / Въпроси

Key Applications

High Performance Computing
VDI
AI/Deep Learning Training
Media/Video Streaming
Cloud Gaming
Animation and Modeling
Design & Visualization
3D Rendering
Diagnostic Imaging

Key Features

5th/4th Gen Intel® Xeon® Scalable processor support
32 DIMM slots; up to 8TB (32x 256GB DRAM DDR5-5600MT/s ECC)
AIOM/OCP 3.0 Support
13 PCIe Gen 5.0 x16 FHFL slots
8x hot-swap 2.5” SATA/SAS (AOC required)
8 hot-swap 2.5" SATA drive bays
8 hot-swap 2.5" NVMe drive bays
8x hot-swap Heavy Duty Fans with Optimal Fan Speed Control
4x 2700W (2+2) Redundant Power Supplies, Titanium Level

Specification	Details
Model	Super X13DEG-OA
CPU Socket	Dual Socket E (LGA-4677)
Supported CPUs	5th Gen Intel Xeon / 4th Gen Intel Xeon Scalable
Core Count	Up to 64C / 128T per CPU
Cache	Up to 320MB Cache per CPU
Max TDP	Up to 350W (Air Cooled)
Max GPU Count	Up to 10 double-width or 10 single-width GPUs
Supported GPUs	NVIDIA A10, L4, L40, L40S, RTX 5000 Ada, RTX 6000 Ada, RTX A4000
CPU-GPU Interconnect	PCIe 5.0 x16 Switch Dual-Root
GPU-GPU Interconnect	NVIDIA NVLink Bridge (optional), Intel Xe Link Bridges
DIMM Slots	32 DDR5 DIMM slots
Max Memory (1DPC)	Up to 4TB @ 5600MT/s ECC RDIMM
Max Memory (2DPC)	Up to 8TB @ 4400MT/s ECC RDIMM
Memory Voltage	1.1V
Chipset	Intel C741
Network	2× RJ45 10GbE (Intel X710-AT2)
Video	1× VGA port
BIOS Type	AMI 32MB SPI Flash EEPROM
Tools	SuperCloud Composer, SSM, SUM, SD5, SDO, TAS, SAA
Power Configurations	AC power recovery, ACPI Power Management
TPM	TPM 2.0
Root of Trust	Silicon RoT (NIST 800-193 compliant)
Secure Boot	Yes
Firmware Security	Signed Firmware, Secure Updates, Auto Recovery
Supply Chain Security	Remote Attestation
Runtime Protection	BMC Protections, System Lockdown
CPU VRM	8+4 Phase Voltage Regulator
Monitoring	CPU cores, chipset voltages, memory
Fan Monitoring	Tachometer, PWM fan control, speed monitoring
Temperature	CPU & chassis monitoring, thermal fan control
Form Factor	4U Rackmount
Model	CSE-418G2TS-R5K40P
Height	7" (178 mm)
Width	17.2" (437 mm)
Depth	29" (737 mm)
Package Size	26.57" (H) × 27" (W) × 41" (D)
Gross Weight	100 lbs (45.3 kg)
Net Weight	65.5 lbs (29.7 kg)
Available Color	Black Front & Silver Body
Buttons	Power On/Off, System Reset
LEDs	HDD Activity, Network Activity, Power Status, Overheat & Power Fail
PCIe Slots	13× PCIe 5.0 x16 FHFL slots
Default Configuration	16 bays (8× 2.5" NVMe + 8× 2.5" SATA hot-swap)
Option A	24 bays (8 NVMe + 8 NVMe* + 8 SATA)
NVMe Note	NVMe may require additional controller/cables
M.2 Slots	2× M.2 NVMe (M-key)
Fans	Up to 8 heavy-duty fans with speed control
PSU Count	4× 2700W redundant
Efficiency	Titanium Level (96%)
Input Voltage	200–240Vac / 240Vdc
+12V Output	Max 225A
12V Standby	3.5A–4A
PSU Dimensions	73.5 × 40 × 203 mm
Output Type	Backplanes (gold finger)
