Honeywell PTM7950 TIM
The Honeywell PTM7950 Thermal Interface Material (TIM) offers a premium solution for high-performance electronics, particularly in the demanding field of graphics processing units (GPUs). The PTM7950 delivers superior thermal conductivity, enhancing the reliability and longevity of graphics cards by its outstanding material characteristics.
Free Flow
The Free Flow cooling design is tailored for axial fan systems, featuring an advanced heatsink fin module that optimizes airflow paths. By reducing turbulence and channeling air efficiently, it maximizes heat dissipation, ensuring consistent performance even under heavy thermal loads.
AeroCurve Fan Blade
The latest fan blade design builds upon its predecessor with advancements that reduce air friction, increasing the usable fan RPM range while maintaining low noise levels. This refined design ensures improved airflow, optimized static pressure, and enhanced cooling efficiency for demanding applications.
Optimized Composite Heatpipe
The composite heatpipes are fine-tuned for each individual cooling design with optimal heat flow, efficiently and evenly spreading out the heat to the entire cooling module.
Integrated Cooling Module
Integrated Cooling is an advanced thermal management solution engineered to provide efficient heat dissipation across all critical components of a graphics card. This innovative design ensures direct contact with the GPU, memory modules, and VRMs, delivering uniform thermal regulation. By addressing all major heat sources, the Integrated Cooling Module helps maintain stable operating temperatures, improving overall system performance and reliability. Ideal for demanding workloads such as gaming, content creation, and overclocking, it ensures optimal thermal efficiency under sustained use.
FrameDefense
The mechanical design of the graphics card features a robust, box-like frame that ensures exceptional build quality and durability. This solid construction provides a protective enclosure for all internal components, reducing the risk of damage during handling or installation. This rigid frame offers added stability and strength, making it highly resistant to accidental impacts or pressure, ensuring that the delicate components, such as the GPU, memory, and VRMs, remain secure. With this design, users can confidently handle the card without worrying about compromising its integrity or performance.
Specification | |
---|---|
Architecture | AMD RDNA 4 |
Engine Clock | Boost Clock: Up to 3290 MHzGame Clock: Up to 2700 MHz |
Stream Processors | 2048 |
Compute Units | 32 CUs (3rd Gen RT + 2nd Gen AI Accelerators) |
Infinity Cache | 32MB |
Ray Accelerators | 32 |
AI Accelerators | 64 |
Memory | 16GB GDDR6 on 128-bit bus |
Memory Clock | 20 Gbps Effective |
Display Outputs | 2x HDMI 1x DisplayPort 2.1a |
Max Displays | 3 |
Max Resolution | HDMI: 7680×4320DisplayPort 2.1a: 7680×4320 |
Interface | PCI-Express 5.0 x16 |
BIOS Support | UEFI |
Game Index | 1440p Gaming |
Cooler Type | Dual-X CoolingAeroCurve Fan BladeIntegrated Cooling ModuleFree Flow |
Sapphire Features | Honeywell PTM7950 TIMFrameDefenseMetal BackplateTriXX Boost, etc. |
AMD Features | AMD HYPR-RX w/ AFMF 2FidelityFX Super Resolution 4Anti-Lag 2Fluid Motion Frames 2, etc. |
Form Factor | 2.3 slot, ATX240(L) x 124(W) x 46.1(H) mm |
Power Consumption | 170W Typical Board Power |
System Requirements | 450W PSU min.1 x 8-pin Power ConnectorPCIe x16 Slot8GB RAM (16GB recommended) |
