Qnap TS-932PX-4G
НазадQnap TS-932PX-4GQnap TS-932PX-4GQnap TS-932PX-4GQnap TS-932PX-4GНапред

Мрежови диск (NAS) Qnap TS-932PX-4G, четириядрен Alpine AL324 1.7GHz, без твърд диск (5x 3.5-inch+ 4 x 2.5-inch SATA 6Gb/s), 4GB RAM, 2x 10/100/1000/2500 LAN, 3x USB 3.2 Gen 2

id 303777 Код: NASQNAPTS932PX4G

930.22 €

Печат

Изпрати на приятел

ОписаниеХарактеристикиРевюта / ВъпросиВземи на изплащане

Qnap TS-932PX-4G
Compact 9-bay NAS with 10GbE SFP+ and 2.5GbE for Smoother File Applications

The quad-core 1.7GHz TS-932PX fits nine drive bays into the size of a 5-bay NAS. With five 3.5-inch SATA 6Gb/s drive bays and four 2.5-inch SATA 6Gb/s bays, the TS-932PX provides the ability to create an HDD/SSD hybrid infrastructure to boost application performance. With two 10GbE SFP+ and two 2.5GbE LAN ports, the TS-932PX supports next-generation networks for empowering bandwidth-demanding applications and providing smoother file access and sharing.




CPUAnnapurnaLabs Alpine AL324 ARM® Cortex-A57 4-core 1.7GHz processor
CPU Architecture64-bit ARM
Floating Point UnitYes
Encryption EngineYes
System Memory4 GB SODIMM DDR4
Maximum Memory16 GB (1 x 16 GB)
Memory Slot1 x SODIMM DDR4
Flash Memory512 MB (Dual boot OS protection)
Drive Bay5x 3.5-inch+ 4 x 2.5-inch SATA 6Gb/s
Drive Compatibility3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives

2.5-inch bays:
2.5-inch solid state drives
Hot-swappable
SSD Cache Acceleration Support
2.5 Gigabit Ethernet Port (2.5G/1G/100M)2 (2.5G/1G/100M/10M)
10 Gigabit Ethernet Port2 x 10GbE SFP+
Wake on LAN (WOL)Only the 2.5GbE port
Jumbo Frame
USB 3.2 Gen 1 port3
Form FactorTower
LED IndicatorsSystem Status, LAN, USB, HDD1~5, SSD1-4
ButtonsPower, Reset, USB Copy
Dimensions (HxWxD)

176.5 × 224.6 × 224.1 mm

Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model)

Weight (Net)4.66 kg
Weight (Gross)5.2 kg
Operating Temperature0 - 40 °C (32°F - 104°F)
Storage Temperature-20 - 70°C (-4°F - 158°F)
Relative Humidity5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply UnitExternal, 120 W, AC 100 to 240 V
Power Consumption: Disk Standby Mode23.833 W
Power Consumption: Operating Mode, Typical

43.003 W

Tested with drives fully populated.

Fan1 x 140mm, 12VDC
System WarningVoice prompts or Buzzer




    Виж още Мрежови дискове NAS Qnap
    Виж всички Мрежови дискове NAS в категорията
    Технически характеристики
    Формфактор:  Tower
    Капацитет:  Неокомплектован GB
