3ware 9690SA-8I-SGL RAID Controller SAS 8-Port Internal 512MB PCIe Low-profile Single w/o Cables
Features and Benefits:
# AMCC’s 3ware 9690SA SAS/SATA hardware RAID controllers deliver industry-leading RAID 6 and RAID 5 performance, expanded scalability, robust fault tolerance, and multi-terabyte capacities. A PCI Express host interface, StorSwitch™ architecture and sophisticated SAS and SATA II features drive this unrivaled performance. Scalable to 128 SAS and/or Serial ATA devices
# PCI Express eight lane (x8) host interface
# Configuration flexibility with eight internal/external ports, or four internal/external ports.
# SAS, SATA, and SATA II features, including 3Gb/s and NCQ.
# 512MB DDR2 533 fixed memory
# Simultaneous double parity generation to maximize RAID 6 performance
# StorSwitch™ 8th generation non-block-ing switch fabric for maximum controller throughput
# StreamFusion optimizes I/O accesses to maximize application performance under multiple stream loads
# StorSave BBU with write journaling optimizes data protection and performance
# Low-profile form factor
# RAID levels 0, 1, 5, 6, 10, 50, and Single Disk.
Specifications:
Device Type: Storage controller (RAID)
Form Factor: Low Profile Plug-in card
Supported Device: Hard drive; Disk array (RAID)
Controller Interface Type: SAS 1.1 support, SATA 2.6 support.
SAS Ports: 8x Internal Ports
Host Interface: PCI Express x8 configurations, PCI Express 1.1 compliant.
PCI Express Lanes: 8
Data Transfer Rate: 3.0 Gbps
Onboard Memory: 512MB DDR2 533
RAID Levels: 0, 1, 5, 6, 10, 50, Single Disk.
Connector Type: 8087 mini-SAS
Remote BBU Support: Yes (optional)
Operating Temperature: Controller 0°C to 50°C, BBU 10°C to 40°C.
Power Requirements: 18W maximum
Dimensions (L x H): 7.60” x 2.73” (19.30cm x 6.93cm)
Operating System Support:
Microsoft® Windows® Vista/2003/XP,
Red Hat Linux, SuSE Linux, Fedora Linux, 2.4 Linux kernel, 2.6 Linux kernel, FreeBSD;
32/64-bit driver support for Windows, Linux and FreeBSD.
http://www.acmemicro.com/estore/merchant.ihtml?pid=4874&step=4
Виж още Контролери AMCC
Виж всички Контролери в категорията
Features and Benefits:
# AMCC’s 3ware 9690SA SAS/SATA hardware RAID controllers deliver industry-leading RAID 6 and RAID 5 performance, expanded scalability, robust fault tolerance, and multi-terabyte capacities. A PCI Express host interface, StorSwitch™ architecture and sophisticated SAS and SATA II features drive this unrivaled performance. Scalable to 128 SAS and/or Serial ATA devices
# PCI Express eight lane (x8) host interface
# Configuration flexibility with eight internal/external ports, or four internal/external ports.
# SAS, SATA, and SATA II features, including 3Gb/s and NCQ.
# 512MB DDR2 533 fixed memory
# Simultaneous double parity generation to maximize RAID 6 performance
# StorSwitch™ 8th generation non-block-ing switch fabric for maximum controller throughput
# StreamFusion optimizes I/O accesses to maximize application performance under multiple stream loads
# StorSave BBU with write journaling optimizes data protection and performance
# Low-profile form factor
# RAID levels 0, 1, 5, 6, 10, 50, and Single Disk.
Specifications:
Device Type: Storage controller (RAID)
Form Factor: Low Profile Plug-in card
Supported Device: Hard drive; Disk array (RAID)
Controller Interface Type: SAS 1.1 support, SATA 2.6 support.
SAS Ports: 8x Internal Ports
Host Interface: PCI Express x8 configurations, PCI Express 1.1 compliant.
PCI Express Lanes: 8
Data Transfer Rate: 3.0 Gbps
Onboard Memory: 512MB DDR2 533
RAID Levels: 0, 1, 5, 6, 10, 50, Single Disk.
Connector Type: 8087 mini-SAS
Remote BBU Support: Yes (optional)
Operating Temperature: Controller 0°C to 50°C, BBU 10°C to 40°C.
Power Requirements: 18W maximum
Dimensions (L x H): 7.60” x 2.73” (19.30cm x 6.93cm)
Operating System Support:
Microsoft® Windows® Vista/2003/XP,
Red Hat Linux, SuSE Linux, Fedora Linux, 2.4 Linux kernel, 2.6 Linux kernel, FreeBSD;
32/64-bit driver support for Windows, Linux and FreeBSD.
http://www.acmemicro.com/estore/merchant.ihtml?pid=4874&step=4
JAR Computers може да предложи ремонт/смяна/монтаж в наш сервиз или при партньор.
Виж още Контролери AMCC
Виж всички Контролери в категорията
Технически характеристики
| Тип: | Контролер |
|---|---|
| От какъв интерфейс: | PCI Express x8 |
| Към какъв интерфейс: | SAS |
