- Port Configuration
| 10M/100M/1G RJ45 Port | 8 |
| 100M/1G SFP Port | 2 |
| Total Ports | 10 |
- HW Performance
| Switching Bandwidth | 20Gbps |
| Forwarding Performance | 14.88Mpps |
| MAC Address | 8K |
| Jumbo Frames | 9216 Bytes |
- Environmental Specification
| Operating Temperature | 0°C to 50°C |
| Operating Humidity | 10 to 90% RH |
| Storage Temperature | -20°C to 70°C |
| Storage Humidity | 10 to 90% RH |
- Mechanical Specification
| Dimensions (H) x (W) x (D) mm | 44 x 220 x 134 |
| Weight | < 1.5 Kg |
| FAN Less |
- Power Source
| AC Input | 100V-240V |
| DC Input | — |
| Dual Input | — |
- Certifications
| EN61000-4-5 (for RJ45 Port, Surge 6KV) | — |
| Certifications | CE/FCC Class A |
L2 Switching
| Spanning Tree | IEEE802.1D (STP) | Y |
| IEEE802.1W (RSTP) | Y | |
| IEEE802.1S (MSTP) | Y | |
| VLAN | 802.1Q VLAN | Y |
| Port-Based | Y | |
| VLAN Entries | 4K | |
| Private VLAN | Y | |
| Voice VLAN | Y | |
| Guest VLAN | — | |
| Q-in-Q | Y | |
| 802.1v Protocol VLAN | Y | |
| MAC-Based VLAN | Y | |
| IP Subnet-Based VLAN | Y | |
| IEEE 802.3ad LACP | Dynamic Trunk | Y |
| Static Trunk | Y | |
| GARP/GVRP | Option | |
| IGMP Snooping | Y | |
| MLD Snooping | Y | |
| Multicast VLAN Registration (MVR) | Y |
- L3 Features
| Static Route | — |
| DHCP Server | Y |
- QoS Features
| Class of Service | Port Based | Y |
| 802.1p | Y | |
| DSCP | Y | |
| TCP/UDP Port | — | |
| Rate Limiting | Ingress | Y |
| Egress | Y | |
| Priority Queue Scheduling | WRR | Y |
| Strict Priority | Y | |
| Hardware Queues | 8 |
- Security
| ACLs | L2/L3/L4 | Y |
| IPv6 Support | — | |
| Port Security (MAC-based) | Y | |
| IP Source Guard | Y | |
| Storm Control | Y | |
| RADIUS Authentication 802.1x | Y | |
| TACACS+ Authentication | Y | |
| HTTPs and SSL (Secured Web) | Y | |
| BPDU Guard | Y | |
| STP Root Guard | Y | |
| DHCP Snooping | Y | |
| Loop Protection | Y |
- Management
| DHCP | Client | Y |
| Relay | Y | |
| Option 66 | Y | |
| Option 67 | Y | |
| Option 82 | Y | |
| Event/Error Log | Syslog | Y |
| SMTP (RFC821) | Y | |
| Management Access Filtering | SNMP | Y |
| Web | Y | |
| Telnet | Y | |
| SSH | Y | |
| PoE Management | Scheduling | — |
| Auto-Checking | — | |
| Power Delay | — | |
| SNMP (v1, v2c, v3) | Y | |
| RMON ( 1,2,3 & 9 Groups) | Y | |
| Software Upgrade | Y | |
| Configuration Export/Import | Y | |
| Port Mirroring | Y | |
| LLDP (IEEE802.1AB) | Y | |
| LLDP-MED (IEEE802.1AB) | Y | |
| CDP Aware | Y | |
| sFlow | Option | |
| IPv6 Management | Y | |
| NTP | Y |
- Device Management System
| Device Management | Topology View |
| |
| Floor View |
| ||
| Map View |
| ||
| Dashboard |
| ||
| Traffic Monitoring |
| ||
| Cable Diagnostics |
| ||
| Switch2go | iOS Devices | — | |
| Android Devices | — | ||
| Find my Switch | iOS Devices | — | |
| Android Devices | — | ||
| Tech Support Online | — |
