Product benefits
- Great scope of design options due to long and flexible LED strips
- Easy installation, no tools required for connection
- Easy mounting on many smooth surfaces thanks to self-adhesive tape
- Maximum flexibility due to large range of accessories
- Simple connection thanks to integrated cables on both sides
Areas of application
- General indoor illumination
- Decorative illumination
- Private living areas
Technical data
Electrical data
| Nominal wattage | 60.00 W |
| Construction wattage | 60.00 W |
| Nominal wattage per meter | 13.2 W |
| Nominal voltage | 24 V |
| Input voltage range | 23…25 V |
| Type of current | DC |
| Nominal current | 2500 mA |
Photometrical data
| Luminous efficacy | 113 lm/W 1) |
| Luminous flux | 6180 lm |
| Luminous flux per meter | 1490 lm 1) |
| Color temperature | 6500 K |
| Color rendering index Ra | > 80 |
| Light color LED | Cold White |
| Light color (designation) | Cold White |
| Standard deviation of color matching | ≤5 sdcm |
1) Value based on first meter of the product
Light technical data
| Beam angle | 120 ° |
| Rated beam angle (half peak value) | 120.00 ° |
LED MODULE INFORMATION
| Number of LEDs per meter | 70 |
| Number of LEDs per module | 350 |
| Number of LEDs per smallest unit | 7 |
Dimensions & Weight
| Length | 5000.00 mm |
| Length – smallest unit | 100 mm |
| Cable length | 500.000 |
| Width | 8.00 mm |
| Height | 1.50 mm |
| Prewired | Yes |
| Conductor cross section | 0.5 mm² |
| LED pitch | 14.29 mm |
| Short pitch | No |
| Product weight | 78.00 g |
Temperatures & operating conditions
| Ambient temperature range | -20…+55 °C |
| Maximum temperature at tc test point | 75 °C |
Lifespan
| Nominal lamp life time | 30000 h |
Capabilities
| Dimmable | Yes 1) |
| Lowest bending radius | 30,0 mm |
| Self-adhesive | Yes |
1) Dimmable with suitable drivers, see also www.ledvance.com/dim
Certificates & Standards
| Approval marks – approval | CE, TUV |
| Protection class | III |
| Type of protection | IP00 |
| Energy class of contained light source | F |
| Salt mist resistance acc. IEC 60068-2-52 | No |
| UV resistance acc. IEC 60068-2-5 | No |
LOGISTICAL DATA
| Temperature range at storage | -20…+80 °C |
PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
Виж още LED Ленти Ledvance
Виж всички LED Ленти в категорията
Технически характеристики
| Тип: | Гъвкава лента |
|---|---|
| Светлоизточник: | Не е указано |
| Влагозащитеност: | IP00 (Незащитена) |
| Мощност: | 60 W |
| Напрежение: | 24 V |
| Светлинен поток: | 6180 lm |
| Дължина: | 5 m |
| Цветна температура: | Студено бяла |
| Особеност: | Няма |
