Warning: Bulb is not included !
Product benefits
- High flexibility in the choice of the light source thanks to E27 socket
- Easy and quick installation
Areas of application
- Building facades
- Entrance lighting
- Patios, balconies
- Pathway lighting
- Driveways
Product features
- Available with and without motion sensor
- Stainless steel housing
- Type of protection: IP44
Safety advice
- All electrical connections must be made by a qualified person.
- Caution, risk of electric shock.
- Product in protection class I. All electrically conductive, metallic housing parts that can absorb voltage during operation or during maintenance in the event of a fault must be continuously connected to the protective earthing conductor.
Technical data
Electrical data
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Power factor λ | > 0.50 |
| Protection class | I |
| Operating mode | Mains voltage |
Photometrical data
| Standard deviation of color matching | < 6 sdcm |
Dimensions & Weight
| Length | 161.00 mm |
| Height | 305.00 mm |
| Width | 120.00 mm |
| Product weight | 950.00 g |
Materials & Colors
| Product color | Steel |
| Housing color | Steel |
| Body material | Stainless steel |
| Cover material | Glass |
| Mercury content | 0.0 mg |
Application & Mounting
| Ambient temperature range | -20…+40 °C |
| Type of connection | Terminal, 3-Pole (L, N, PE) |
| Type of protection | IP44 |
| Dimmable | No |
| Mounting type | Surface |
| Mounting location | Wall |
| Application environment | Outdoor |
| With light source | No |
| Replaceable light source | No |
Sensor
| Type of sensor | Light, Motion |
| Sensor technology | Passive infrared (PIR) |
| Sensor detection angle | 90 ° |
| Sensor controlled switching time | 5 s…6 min |
| Detection range of motion sensor | 5…8 m |
| Detection threshold of daylight sensor | 0…30 lx |
Certificates & Standards
| Standards | CE, EAC, UKCA |
| Luminaire with limited surface temperature, "D sign" | No |
Additional product data
| Product remark | Maximum bulb wattage: 60 W |
PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS
| Quantity of precious metals | 0 mg |
| Quantity of rare earths | 0 mg |
Виж още LED Екстериорно осветление Ledvance
Виж всички LED Екстериорно осветление в категорията
Документация
Техническа спецификацияТехнически характеристики
| Тип: | Фасадно осветление |
|---|---|
| Монтаж: | Стена |
| Влагозащитеност: | IP44 (Външна употреба) |
| Мощност: | Не е указано W |
| Напрежение: | 240V V |
| Светлинен поток: | Не е указано lm |
| Цветна температура: | Не е указано |
| Цвят на корпуса: | Неръждаема стомана |
| Особеност: | Сензор |
