Грамофон Pro-Ject 6 PerspeX SB, Ortofon Quintet Blue доза, 33/45rpm, черен

Pro-Ject 6 PerspeX SB Quintet Blue







The transparent acrylic plinth stands on three individually height-adjustable TPE-damped aluminium cones and carries the motor and the sub-chassis. The sub-chassis, made of Corian, rests on three magnetic fields. A magnetic sub-chassis suspension system avoids parasitic noise normally caused by conventional spring mechanism. A supplied spirit level allows easy adjustment of the sub-chassis. A quiet running AC motor unit drives the platter’s outside edge via a belt. It does incorporate an advanced DC-driven motor control, that ensures perfect speed stability and electronic speed change.

The resonance-optimised platter is a sandwich construction utilising a fine-balanced medium density fibre platter and a 4 mm thick flat-ground layer of vinyl and a screw-down metal record clamp. It runs on an inverted bearing with stainless-steel axle carrying a ceramic ball/ plate bearing. The headshell and armtube of high-end tonearm 9cc Evolution are fashioned from a single piece of carbon-fibre. A conical armtube avoids standing wave reflections. An Inverted tonearm bearing comprises four hardened stainless tips in ABEC 7 spec ballraces.







Supplied either with or without a premium Quintet Blue cartridge, manufactured by the cartridge experts at Ortofon, it can be ready to play within a few minutes of unboxing. Supplied counterweights are suitable for cartridges weighing between 5-14 g. Also supplied in the box is our Connect-IT E RCA cables, a semi-balanced, low-capacitance cable with superior shielding that’s optimized for turntable use.







Технически характеристики

Speed	33, 45 (electronic speed change)
Principle	Belt drive
Platter	300 mm MDF/vinyl Sandwich
Main bearing	Inverted stainless steel with ceramic ball/plate
Wow & flutter	33: +/- 0.06% 45: +/- 0.06%
Speed variance	33: +/- 0.10% 45: +/- 0.10%
Signal to Noise	73 dB
Tonearm	9” cc EVO, Carbon
Effective arm length	230 mm
Effective tonearmmass	8.0 g
Overhang	18.0 mm
Tracking force range	10 - 35 mN
Included accessory	15 volts DC / 800 mA power supply, dust cover
Power consumption	6 Watts max / < 0.3 Watt standby
Dimensions	460 x 183 x 365 mm (WxHxD)
Weight	11.0 kg net
