GB H310M S2H 2.0

[Socket]: 1151

[Graphics]: Integrated Graphics Processor-Intel® HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz; 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz; * The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz; * Support for HDMI 1.4 version and HDCP 2.2. Maximum shared memory of 1 GB; Maximum support of 2 independent display at one time.

[CPU's supported]: Support for 8th Generation Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package; L3 cache varies with CPU

[Chipset]: Intel® H310 Express Chipset

[Expansion Slots]: 1 x PCI Express x16 slot, running at x16; (The PCIEX16 slot conforms to PCI Express 3.0 standard.); 2 x PCI Express x1 slots; (The PCI Express x1 slots conform to PCI Express 2.0 standard.)

[Storage]: Chipset: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x2 SSD support); 4 x SATA 6Gb/s connectors; * Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.

[Memory type]: 2 x DDR4 DIMM sockets supporting up to 32 GB of system memory; Dual channel memory architecture; Support for DDR4 2666/2400/2133 MHz memory modules; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for Extreme Memory Profile (XMP) memory modules

[I/O]: 1 x PS/2 keyboard port; 1 x PS/2 mouse port; 1 x D-Sub port; 1 x DVI-D port; 1 x HDMI port; 2 x USB 3.1 Gen 1 ports; 4 x USB 2.0/1.1 ports; 1 x RJ-45 port; 3 x audio jacks

[Connectors]: 1 x 24-pin ATX main power connector; 1 x 8-pin ATX 12V power connector; 1 x CPU fan header; 1 x system fan header; 1 x M.2 Socket 3 connector; 4 x SATA 6Gb/s connectors; 1 x front panel header; 1 x front panel audio header; 1 x USB 3.1 Gen 1 header; 1 x USB 2.0/1.1 header; 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only); 1 x speaker header; 1 x Clear CMOS jumper

[Audio]: Realtek® ALC887 codec; High Definition Audio; 2/4/5.1/7.1-channel

[LAN]: Realtek® GbE LAN chip (10/100/1000 Mbit)

[BIOS]: 1 x 128 Mbit flash; Use of licensed AMI UEFI BIOS; PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

[Form Factor]: Micro ATX Form Factor; 22.6cm x 18.5cm

[OS]: Support for Windows 10 64-bit

[Warranty]: 36 Months
