UPS Eaton Ellipse PRO 650, 650VA/400W, Line interactive, Tower

EATON UPS Ellipse PRO 650 FR rack/tower - AC 230 V - 400 Watt - 650 VA 4 Output FR - 2U - 19inch

General
Device Type: UPS - external
Height (Rack Units): 2U
Rack Size: 19"

Power Device
UPS Technology: Line interactive
Input Voltage: AC 230 V
Input Voltage Range: AC 165 - 285 V
Input Voltage Range (Adjustable): AC 150 - 285 V
Frequency Provided: 50/60 Hz
Frequency Required: 50/60 Hz
Input Connectors: 1 x power IEC 60320 C14
Power Output Connectors Details
3 x power CEE 7/5 (UPS and surge)
1 x power CEE 7/5 (surge)
Output Voltage AC 220/230/240 V + 15% / - 20% - 50/60 Hz
Power Capacity 400 Watt / 650 VA
Dataline Surge Protection: Network/phone line - RJ-45/RJ-11 - 1 input line / 1 output line
Surge Suppression: Yes
Circuit Protection: Circuit breaker

Battery
Technology: Lead Acid
Capacity: 7 Ah
Run Time (Up To)
9 min at half load
5 min at 70% load

Networking
Remote Management Interface: USB

Expansion / Connectivity
Interfaces: 1 x management (USB) - 4 pin USB Type B

Miscellaneous
Cables Included: USB cable - external
Rack Mounting Kit: Optional
Features: Wall mountable, LCD display, Automatic Voltage Regulation (AVR), deep discharge protection, cold-start function, EcoControl Master/Control outlets
Compliant Standards: CB, IEC 62040-1-1, IEC 62040-2, IEC 61643-1, EN 62040-1-1, EN 62040-2

Dimensions & Weight
Width: 8.2 cm
Depth: 28.5 cm
Height: 26 cm
Weight: 6.6 kg
