Проектор BenQ MW855UST+, DLP, WXGA (1280 x 800), 10 000:1, 3500lm, HDMI, VGA, LAN, USB

MW855UST+ 3500lms WXGA Education
Paving the Way for Cutting-Edge Classroom Interaction
Ultra short-throw ratio
DLP technology for long-lasting picture perfection
PointWrite Interactive Solution Compatible

Specifications:

Optical

Throw Ratio

0.35

Zoom Ratio

Fixed

Lens Control

Manual Focus

Lens Shift

Vertical: ±2%

Keystone Correction

2D, Vertical ± 15 degrees; Horizontal ± 15 degrees

Projection Offset**

122±5%( (Full-Height)

Projection Size (diagonal)

80"~100" (with wall mount)

Display

Projection System

DLP Single 0.65" WXGA

Resolution

1280 x 800 pixels, 16:10

Brightness

3,500 Lumens

Display Color

1.07 Billion Colors

Aspect Ratio

Native 16:10 (5 aspect ratio selectable)

Light Source

Lamp (240W)

Light Source Life*

Normal 5000 hrs;Economic 8000 hrs;SmartEco 10000 hrs;LampSave 12000 hrs

Contrast Ratio

10,000:1

DMD Type

DC3 DMD chip

Audio

Built-in Speaker

10W x2

Special Feature

Security Lock

Security Bar, Kensington anti-theft lock slot

Feature

Feature

2D Keystone, Corner Fit, Digital zoom(2x), Digital Shrink(0.8x) and Shift, LAN Control, AMX/ PJ Link/Crestron/MDA,DMS Local Compatibility Optional Wireless Display, Optional Interactive module (PW30U/PT20) compatibility.

Connectivity

I/O Port

HDMI-1 X 1
HDMI-2 X 1
PC (D-sub 15pin) X 1
Monitor out (D-sub 15pin,Female) X 1
Composite Video in (RCA) X 1
Audio in(mini jack) X 1
Audio L/R in (RCA) X 1
Audio out (mini jack) X 1
LAN Port(RJ45 for Network ) X 1
RS232 In (D-sub 9pin, male) X 1
USB TypeA (5V,1.5A) X 1
USB Type B (For service) X 1
USB Type mini B (For PointWrite module) X 1
IR Receiver(Front) X 1

Compatibility

Resolution Support

VGA(640 x 480) to WUXGA_RB(1920 x 1200)

Horizontal Frequency

15~102KHz

Vertical Scan Rate

23 ~ 120 Hz

HDTV Compatibility

480i, 480p, 576i, 567p, 720p, 1080i, 1080p

Video Compatibility

NTSC, PAL, SECAM

Power

Power Consumption (Max/Normal/Eco)

Max 350W. Normal 320 W. Eco 260 W.

Standby Power Consumption

Normal < 0.5Watts. Network < 2W.

Dimension and Weight

Product Dimensions (WxHxD)

287.5x 206.9 x 373.3 mm

Product Weight

5 Kg+/- 100g

Operation Condition

Operating Temperature

0o ~ 40oC

Noise Level (Normal/Eco)

34/29 dBA

Accessories

Accessories (Standard)

Power Cord (by region)
Remote Control (RCS011)
AAA Battery x 2
VGA cable
Warranty Card (by region)
QSG (4J.JKS01.001)
Regulatory statement x 1
Wall mount (WM04G4)

Accessories (Optional)

3D Glasses (5J.J9H25.002)
PointWrite Kit: PW30U (5A.JJR26.20E)
PointWrite Touch Module: PT20(5A.JJR26.30E)
Wireless Dongle: QCast Mirror (5A.JH328.10X)
Wireless Kit - Instashow WDC10 (9H.JF878.N4X)

OSD

On Screen Display Language

Arabic/ Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/ German/ Greek/ Hindi/ Hungarian/ Italian/ Indonesian/ Japanese/ Korean/ Norwegian/ Polish/ Portuguese/ Romanian/ Russian/ Simplified Chinese/ Spanish/ Swedish/ Turkish/ Thai/ Traditional Chinese (28 languages)

LS2LT1

Lens

F=2.5 f=5.1mm

InstaShow Host

Power Supply

100 ~ 240V AC
