Zebra DS9308-SR4U2100AZE
Offers a Fit-Anywhere Form Factor Coupled With Stylish Aesthetics
From convenience and drug stores to quick-serve restaurants and other retail environments — counterspace is limited, bumps and spills may be an everyday occurrence, and the need for high customer satisfaction is always critical. Introducing the DS9300 Series, the presentation scanner that fits anywhere, scans everything and is built for all-day reliability.
Scan It All
The DS9300 Series instantly captures barcodes in virtually any condition, on any media. And with industry-leading swipe speeds and the widest field of view in its class, the DS9300 Series can capture barcodes as fast as they are presented.

Innovation-Driven Design
With a near-zero footprint, there’s always room for the DS9300 Series, no matter how space-constrained your counters may be. Recessed LEDs automatically dim when not in use — reducing eye annoyance. And the scanner’s ratcheting base offers four positions for convenient scanning.

Maximum Durability and Reliability
The DS9300 is built to handle the knocks and bumps that can happen in the real-world. Spills and dust won't slow it down thanks to an IP52 sealing, even the base is spill proof.

Category | Specification |
---|---|
Physical Characteristics | |
Dimensions | 5.7 in. H × 3.4 in. W × 3.3 in. D (14.5 cm H × 8.6 cm W × 8.3 cm D) |
Weight | 11.2 oz / 318 g |
Input Voltage Range | 4.5 to 5.5 VDC host powered; 4.5 to 5.5 VDC external power supply |
Operating Current (5.0V) | Presentation mode: 335 mATrigger mode: 350 mA |
Standby Current (5.0V) | Presentation mode: 135 mATrigger mode: 75 mA |
Color Options | Alpine White, Midnight Black |
Supported Host Interfaces | USB Certified, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485 |
Keyboard Support | Supports over 90 international keyboards |
TAA Compliance | Trade Agreement Act Compliant (optional on select configurations) |
Electronic Article Surveillance | Compatible with Checkpoint EAS deactivation system |
User Indicators | Good decode LEDs, rear view LEDs, beeper (adjustable tone and volume) |
Performance Characteristics | |
Swipe Speed (Presentation) | Up to 120 in./305 cm per second for 13 mil UPC in optimized mode |
Light Source | Aiming pattern: circular 617 nm amber LED |
Illumination | 660 nm Hyper Red LED |
Imager Field of View | 52° H × 33° V nominal |
Image Sensor | 1280 × 800 pixels |
Minimum Print Contrast | 15% |
Skew Tolerance | ±60° |
Pitch Tolerance | ±60° |
Roll Tolerance | 360° |
Imaging Characteristics | |
Graphics Format Support | Bitmap, JPEG, TIFF |
Image Quality | 109 PPI on a 4.1 in. × 5.8 in. (A6) document |
User Environment | |
Operating Temperature | 32 °F to 122 °F (0 °C to 50 °C) |
Storage Temperature | -40 °F to 158 °F (-40 °C to 70 °C) |
Humidity | 5% to 95% RH, non-condensing |
Drop Specification | Withstands multiple drops at 5.0 ft / 1.5 m to concrete |
Tumble Specification | Withstands 1,000 tumbles in 1.5 ft / 0.5 m tumbler |
Environmental Sealing | IP52 |
Electrostatic Discharge (ESD) | EN61000-4-2: ±15 KV Air, ±8 KV Indirect |
Ambient Light Immunity | 0 to 10,000 foot-candles (0 to 107,700 Lux) |
Regulatory | |
Environmental | EN 50581:2012; RoHS 2011/65/EU (2015/863) - EN 50581:2012, IEC 63000; REACH 1907/2006 |
Electrical Safety | IEC 62368-1 2nd ed.; EN 62368-1:2014/AC:2015; UL/IEC 60950-1 2nd ed.; CAN/CSA C22.2 No.60950-1 2nd ed. |
LED Safety | IEC 62471:2006 (Ed.1.0); EN 62471:2008 (LED) |
EMI/RFI | FCC 47 CFR Part 15B; ICES-003; EN55032; EN55024; EN55035; VCCI; SABS |
