Zebra DS2208-SR00007ZZWW

Key Features

Scan Type: 2D, 1D
Image Sensor: 640x480 pixels
Scan Range: Standard Range
Corded/Cordless: Corded

Category	Specification
Physical Characteristics
Dimensions	Corded DS2208: 6.5 in. H × 2.6 in. W × 3.9 in. D (16.5 × 6.6 × 9.9 cm) Cordless DS2278: 6.9 in. H × 2.6 in. W × 3.5 in. D (17.5 × 6.6 × 9.0 cm) Presentation Cradle: 2.8 in. H × 3.7 in. W × 4.8 in. D (7.2 × 9.4 × 12.2 cm)
Weight	Corded DS2208: 5.7 oz / 161.6 g Cordless DS2278: 7.5 oz / 214 g Cradle: 5.2 oz / 151 g
Input Voltage Range	DS2208/DS2278 & Cradle: 4.5 to 5.5 VDC Host Powered; 4.5 to 5.5 VDC External Power Supply
Current	DS2208 Operating Current: 250 mA @ 5.0V DS2208 Standby Current: 150 mA @ 5.0V Cradle + Micro USB Cable: 500 mA (Standard USB), 1100 mA (BC 1.2 USB)
Color	Nova White, Twilight Black
Supported Host Interfaces	USB, RS232, Keyboard Wedge, TGCS (IBM) 46XX over RS485
Keyboard Support	>90 international keyboards
User Indicators	Direct Decode Indicator, Good Decode LEDs, Rear LEDs, Beeper (adjustable tone & volume)
Performance Characteristics
Motion Tolerance (Handheld)	Up to 5 in./13 cm per second (13 mil UPC)
Swipe Speed (Hands-Free)	Up to 30 in./76.2 cm per second (13 mil UPC)
Light Source	Aiming: Linear 624 nm Amber LED
Illumination	(2) 645 nm Super-Red LEDs
Imager Field of View	32.8° H × 24.8° V (nominal)
Image Sensor	640 × 480 pixels
Minimum Print Contrast	25% reflective difference
Skew/Pitch/Roll Tolerance	±65° / ±65° / 0–360°
Minimum Element Resolution	Code 39: 4.0 mil Code 128: 4.0 mil Data Matrix: 6.0 mil QR Code: 6.7 mil
User Environment
Operating Temperature	DS2208/DS2278: 32°–122°F (0°–50°C) Cradle: 32°–104°F (0°–40°C)
Storage Temperature	-40°–158°F (-40°–70°C)
Humidity	5%–95% RH, non-condensing
Drop Spec	Multiple drops at 5.0 ft/1.5 m to concrete
Tumble Spec	250 tumbles in 1.5 ft/0.5 m tumbler
Environmental Sealing	IP52
Electrostatic Discharge (ESD)	±15 kV Air, ±8 kV Direct, ±8 kV Indirect (EN61000-4-2)
Ambient Light Immunity	0–10,000 Foot Candles (0–107,600 Lux)
Radio Specifications
Bluetooth	Version 4.0 with BLE Range: Class 2, min 30 ft (10 m), up to 300 ft (100 m) with cradle Profiles: Serial Port & HID Output Power: Adjustable down from 2.0 dBm in 8 steps
Battery (DS2278 Cordless)
Capacity / Type	2,400 mAh Li-Ion
Scans per Charge	110,000 scans @ 60 scans/min 50,000 scans @ 10 scans/min
Operating Time	Up to 84 hours
Charge Time (14 hr shift / Full)	Standard USB: 4 hrs / 17 hrs BC1.2 USB: 1 hr / 5 hrs External 5V: 1 hr / 5 hrs Micro USB: 1 hr / 7 hrs BC1.2 Micro USB: 1 hr / 4 hrs
Regulatory
Electrical Safety	EN 60950-1, IEC 60950-1, UL 60950-1, CAN/CSA-C22.2 No. 60950-1-07
Environmental	RoHS EN 50581
LED Safety	IEC 62471
IT Emissions	EN 55032 (Class B)
IT Immunity	EN 55024
Harmonic Current	EN 61000-3-2
Voltage Fluctuation & Flicker	EN 61000-3-3
Radio Frequency Devices	47 CFR Part 15, Subpart B, Class B
Digital Apparatus	ICES-003 Issue 6, Class B
