Vestel IFD86TH650B/3
| Panel | |
| Screen Size | 86" |
| Panel Technology | IPS |
| Backlight Type | Edge-Type LED |
| Brightness (typical) | 400 cd/m² |
| Native Resolution | UHD: 3840 x 2160 - HDR10 |
| Contrast Ratio (typical) | 1200:1 |
| Dynamic Contrast Ratio | 50000:1 |
| Panel Life Time ( Min. ) | 30000 Hrs |
| Response Time (typical) | 8 ms |
| Active Area (H x V) | 1907 x 1076 mm |
| Pixel Pitch (H x V) | 0.4935 x 0.4935 mm |
| PPI (pixel per inch) | 52 |
| Viewing Angle | 178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10 |
| Color Value | 1.07 B (10-bit) |
| Screen Treatment | 2H |
| Haze Level | 8% |
| Refresh Rate | 120 Hz |
| Front Type | Black Touch Bezel Type |
| Orientation | Horizontal |
| Operation Hours | 16/7 |
| Area of Usage | Indoor |
| Built-in System | |
| Mainboard Model | 17MB135VS |
| Monitor Connectivity | |
| RGB Input | VGA(DE-15F) |
| RGB Output | N/A |
| Video Input | 3xHDMI2.0, 2xUSB2.0, USB2.0(Internal), 1xMicroSD |
| Video Output | HDMI2.0 |
| Audio Input | Line In L/R |
| Audio Output | Headphone, Optic SPDIF |
| External Control | RS232(DE-9F), 2*Ethernet(RJ45), Service(RJ12) |
| External Sensor | RJ12 |
| Touch Interactivity | |
| Type of Touch Technology | Infrared (IR) Technology |
| Continuous Touch Points | 10 Points |
| Sensitivity | Any touch with finger, gloved hand or pointer |
| Connectivity | HID, TUIO, Flash |
| Compatibility | Windows®7,Windows®8, Windows®10, Vista, XP, Mac® OS, Linux, Android |
| Orientation | Landscape support |
| Calibration | No need |
| Accuracy | %90 |
| Reporting Rate | Up to 450 fps |
| Glass Type | Anti Glared (AG), 4mm Tempered |
| Frame Rate | up to 450 fps |
| Communication | USB 2.0 |
| Power Supply Mode | USB |
| Supply Voltage | DC 5V +/- 5% |
| Average Current | |
| Response Time | |
| Touch Accuracy | +/-2mm (over 90% area) |
| Touch Durability | Unlimited |
| HID Compatibility | Yes USB |
| Object Sizes for Touch | 5mm |
| Mechanical | |
| Product Dimensions (WxDxH) | 1975 x 103 x 1146 mm |
| Package Dimensions (WxDxH) | 2163 x 318 x 1405 mm |
| Product Weight | 90.5 kg |
| Package Weight | 110.6 kg |
| Vesa Mounting | 600 x 400 mm |
| Bezel Width | B:38| T:38 | L/R:38 mm |
| Environmental Conditions | |
| Operating Temperature | +40°C / 0°C |
| Operating Humidity | 90% |
| Power | |
| Power Supply | 110 VAC - 240 VAC |
| Power Consumption | |
| Typical | 280W |
| Maximum | 400 W |
| Deep Standby | ≤0.5W |
| Features | |
| Main Features | USB-Autoplay, Auto-switch on Failover, Control Button Lock, HDMI Wake-Up |
| Mechanical Features | IR Touch, Joystick, IR Extender Support, Rocker Switch, Detachable power cable, Carrying handles, Detachable logo positioning, Cable Holders |
| Optional Features | OPS Compliance |
| Speaker | 2 x 12 W |
