Vestel IFD75T643/A3
| Panel | |
| Screen Size | 75" |
| Panel Technology | IPS |
| Backlight Type | Direct-Type LED |
| Brightness (typical) | 400 cd/m² |
| Native Resolution | 3840 x 2160 (16:9) - UHD |
| Contrast Ratio (typical) | 1200:1 |
| Dynamic Contrast Ratio | 40000:1 |
| Panel Life Time ( Min. ) | 30.000 Hrs |
| Response Time (typical) | 8 ms |
| Active Area (H x V) | 1650 x 928 mm |
| Pixel Pitch (H x V) | 0.429 x 0.429 mm |
| PPI (pixel per inch) | 59 |
| Viewing Angle | 178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10 |
| Color Value | 1.07 B (10-bit) |
| Screen Treatment | 2H |
| Haze Level | 3% |
| Refresh Rate | 60 Hz |
| Front Type | Touch Bezel |
| Orientation | Horizontal |
| Operation Hours | 16/7 Panel |
| Area of Usage | Indoor |
| Built-in System | |
| Mainboard Model | MB150VS |
| Touch Interactivity | |
| Type of Touch Technology | Art der Touch-Technologie |
| Continuous Touch Points | 10 Points |
| Sensitivity | Jegliche Berührungen mit Finger, Handschuh oder Pointer |
| Connectivity | HID, TUIO, Flash |
| Compatibility | Windows®7,Windows®8, Windows®10, Vista, XP, Mac® OS, Linux, Android |
| Orientation | Portrait und Landschaft |
| Calibration | Nicht notwendig |
| Accuracy | 90% |
| Reporting Rate | up to 450 fps |
| Glass Type | Anti Glared (AG), Tempered 4mm |
| Frame Rate | up to 450 fps |
| Communication | USB2.0 |
| Power Supply Mode | USB |
| Supply Voltage | DC 5V +/- 5% |
| Average Current | < 400 mA |
| Response Time | < 10 ms |
| Touch Accuracy | +/-2mm (over 90% area) |
| Touch Durability | unbegrenzt |
| HID Compatibility | YES USB |
| Object Sizes for Touch | 5 mm |
| Inputs | |
| HDMI | YES |
| HDMI Support Type | 1x2.0 |
| Analogue D-SUB | YES |
| USB 2.0 | 1 + 2 for Android |
| USB 3.0 | 1 |
| Internal USB 2.0 | YES (W / Screw Lock) |
| USB Support Type | Photo / Video / MP3 |
| RS232 | DSUB9 |
| RJ12 | Service use only |
| LAN (Control) | 1 + 1 for Android |
| Remote Extender | YES |
| Line In | YES |
| Micro SD | Up to 1TB |
| Outputs | |
| HDMI | YES |
| Mini Jack (Audio) | YES |
| RCA (L/R) | YES |
| Speakers | YES |
| Speakers output | 2x12W |
| Line Out | YES |
| Headphone | YES |
| Mechanical | |
| Product Dimensions (WxDxH) | 1731 x 119 x 1008 mm |
| Package Dimensions (WxDxH) | 1948 x 310 x 1248 mm |
| Product Weight | 58.3 kg |
| Package Weight | 72.4 kg |
| Vesa Mounting | 600 x 400 mm - M6 |
| Bezel Width | B:38 | T:38 | L/R:38 mm |
| Environmental Conditions | |
| Operating Temperature | 0-40°C |
| Operating Humidity | 10-90% |
| Power | |
| Power Supply | 110 VAC - 240 VAC - 50/60 Hz |
| Power Consumption | |
| Off | ≤ 0.5W |
| Features | |
| Main Features | Android 7.1 OS, Open Content Management Support, Scheduler, USB-Autoplay, Auto-Launch, HDMI-CEC, HDMI-Hotplug, Auto-switch on Failover, Panel Lock, OSD Rotation, NoSignalPowerOff, Screen Saver, Pixel shift, Scheduler, Videowall support, remote control via LAN, Real Time Clock |
| Mechanical Features | Joystick, IR Extender Support, Rocker Switch, Detachable power cable, Carrying slots, Detachable logo positioning, Cable Holder |
