Name: Детектор на напрежение UNI-T UT18C, 12 ~ 690V чувствителност, еднополюсен детектор за фаза, идентификация на полюсите, индикация на посоката на въртене на фазите, оранжев
Brand: UNI-T
SKU: MITEDUNITUT18C
Availability: OutOfStock

Описание Характеристики Ревюта / Въпроси

UT18C voltage and continuity tester is designed for testing AC/DC voltage, 3-phase voltage, phase sequence, continuity, and more. This device is categorized as CAT IV 600V and meets IP65 standard. Application fields for UT18C include smelting, electronics, manufacturing, and electrical. It is a perfect tool for electricians, to quickly measure voltage levels in any harsh environments. It should NOT be used in 110V electrical systems.

Features

1. Auto power off, the conductor to be measured is greater than 12V

2. Phase rotation test

3. Continuity test with buzzer and LED indication

4. RCD: Detecting leakage protective switch

5. Low battery Indication and over voltage prompt

6. LED prompt

7. Flashlight

8. Test live voltage without batteries

9. Buzzer and silent mode

10. Auto standот mode

11. Auto range/Inspection

12. Voltage, frequency display

13. Data hold

14. Polarity indication

Specifications	Range	Best Accuracy
Model		UT18C
LED AC/DC Voltage Indication (V)	12V	8V±2V
	24V	18V±2V
	50V	38V±4V
	120V	92V±6V
	230V	174V±8V
	400V	320V±10V
	690V	550V±15V
Phase Rotation Test	Operating Voltage: 100V~690V	√
Phase Rotation Test	Frequency: 50Hz~ 60Hz	√
Single Lead (L2) Voltage Detection	Operating Voltage: 100V~690V	√
Single Lead (L2) Voltage Detection	Frequency: 50Hz~ 400Hz	√
Continuity Test	Resistance: 0~100kΩ	√
Continuity Test	Beeper and LED Light Indicator	√
RCD Test	Operating Voltage: 230V (50Hz～400Hz)	√
Polarity Detection	Positive & Negative	√
Self-inspection	All LED or LCD indicator	√
No Power Test	Operating Voltage: 50VAC/120VDC~690VDC/AC	√
Features
IP65		√
Auto Range	All Range	√
Exceed Voltage	Voltage Range: 713V~788V	√
Auto Standby	Standот Current <10uA	√
Silent Mode	All Range	√
Work Light	All Range	√
Low Battery Indication	Voltage Range: 2.2V~2.4V	√
LCD Display (Voltage+Frequency)	6V~690V (40Hz~400Hz)	±(1.5%+5)
General Characteristics
Power	1.5V Batteries (R03) × 2
LCD Size	31×20mm
Product Color	Red and Grey
Product Net Weight	280g
Product Size	272mm×85mm×31mm
