Product benefits
- Great scope of design options due to long and flexible LED strips
- Easy installation, no tools required for connection
- Easy mounting on many smooth surfaces thanks to self-adhesive tape
- Maximum flexibility due to large range of accessories
- Simple connection thanks to integrated cables on both sides
- Suitable for use in damp conditions thanks to high type of protection
Areas of application
- General indoor illumination
- General outdoor illumination
- Industry
- Offices, retail outlets and conference rooms
- Architecture lighting
- Decorative illumination
Technical data
Electrical data
| Nominal wattage | 21.00 W |
| Construction wattage | 21.00 W |
| Nominal wattage per meter | 4.2 W |
| Nominal voltage | 24 V |
| Input voltage range | 23…25 V |
| Type of current | DC |
| Nominal current | 875 mA |
Photometrical data
| Luminous efficacy | 122 lm/W |
| Luminous flux | 2360 lm |
| Luminous flux per meter | 515 lm |
| Color temperature | 4000 K |
| Color rendering index Ra | > 90 |
| Light color LED | Daylight |
| Light color (designation) | Daylight |
| Standard deviation of color matching | ‹3 sdcm |
Light technical data
| Beam angle | 110 ° |
| Rated beam angle (half peak value) | 110.00 ° |
LED MODULE INFORMATION
| Number of LEDs per meter | 144 |
| Number of LEDs per module | 720 |
| Number of LEDs per smallest unit | 8 |
Dimensions & Weight
| Length | 5000.00 mm |
| Length – smallest unit | 55.56 mm |
| Cable length | 500.000 |
| Width | 10.00 mm |
| Height | 4.70 mm |
| Prewired | Yes |
| Conductor cross section | 0.5 mm² |
| LED pitch | 6.94 mm |
| Short pitch | Yes |
| Product weight | 380.00 g |
Colors & materials
| Cover material | Silicone |
Temperatures & operating conditions
| Ambient temperature range | -20…+55 °C |
| Maximum temperature at tc test point | 80 °C |
Lifespan
| Nominal lamp life time | 50000 h |
Additional product data
| Mounting location | All surfaces |
Capabilities
| Dimmable | Yes 1) |
| Lowest bending radius | 30,0 mm |
| Self-adhesive | Yes |
1) Dimmable with suitable drivers, see also www.ledvance.com/dim
Certificates & Standards
| Approval marks – approval | CE, TUV, ENEC |
| Protection class | III |
| Type of protection | IP67 |
| Energy class of contained light source | E |
| Salt mist resistance acc. IEC 60068-2-52 | Yes |
| UV resistance acc. IEC 60068-2-5 | Yes |
LOGISTICAL DATA
| Temperature range at storage | -20…+80 °C |
PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS
| Quantity of precious metals | Contains at least 10 mg |
| Quantity of rare earths | Contains at least 1 mg |
Виж още LED Ленти Ledvance
Виж всички LED Ленти в категорията
Технически характеристики
| Тип: | Гъвкава лента |
|---|---|
| Светлоизточник: | Не е указано |
| Влагозащитеност: | IP67 (Външна употреба) |
| Мощност: | 21 W |
| Напрежение: | 24 V |
| Светлинен поток: | 2360 lm |
| Дължина: | 0.50 m |
| Цветна температура: | Неутрално бяла |
| Особеност: | Няма |
