Warning: Bulb is not included !
Product benefits
- High flexibility in the choice of the light source thanks to GU10 socket
- Easy and quick installation
- High-quality materials
Areas of application
- Entrance lighting
- Patios, balconies
- Building facades
Product features
- Die-cast aluminum housing
Safety advice
- All electrical connections must be made by a qualified person.
- Caution, risk of electric shock.
- Product in protection class I. All electrically conductive, metallic housing parts that can absorb voltage during operation or during maintenance in the event of a fault must be continuously connected to the protective earthing conductor.
Technical data
Electrical data
| Nominal voltage | 220…240 V |
| Mains frequency | 50…60 Hz |
| Protection class | I |
Photometrical data
| Flickering metric (Pst LM) | - |
| Stroboscope effect metric (SVM) | - |
Dimensions & Weight
| Length | 68.00 mm |
| Height | 92.00 mm |
| Width | 81.00 mm |
| Product weight | 300.00 g |
Materials & Colors
| Product color | Black |
| Housing color | Black |
| Body material | Aluminum |
| Mercury content | 0.0 mg |
Application & Mounting
| Ambient temperature range | -20…+40 °C |
| Type of connection | Terminal, 3-Pole (L, N, PE) |
| Type of protection | IP44 |
| Protection class IK (shock resistance) | IK04 |
| Dimmable | No |
| Mounting type | Surface |
| Application environment | Outdoor |
| With light source | No |
| Replaceable light source | No |
| Holder designation | GU10 |
Certificates & Standards
| Standards | CE, UKCA |
| Luminaire with limited surface temperature, "D sign" | No |
| Ball shot safe | No |
Additional product data
| Product remark | Maximum bulb wattage: 35 W |
| Number of illuminants | 1 |
Виж още LED Екстериорно осветление Ledvance
Виж всички LED Екстериорно осветление в категорията
Документация
Техническа спецификацияТехнически характеристики
| Тип: | Фасадно осветление |
|---|---|
| Монтаж: | Стена |
| Влагозащитеност: | IP44 (Външна употреба) |
| Мощност: | Не е указано W |
| Напрежение: | 240V V |
| Светлинен поток: | Не е указано lm |
| Цветна температура: | Не е указано |
| Цвят на корпуса: | Черен |
| Особеност: | Няма |
